Common Mode Chokes
Browse available Common Mode Chokes components by manufacturer and part number. Review stock status, datasheets and key technical parameters to compare suitable options for design, maintenance, replacement or purchasing.
If you already have a target MPN or BOM, send it to EGOO with the required quantity. Our sourcing team can check availability, lead time and quotation options, including hard-to-find and obsolete parts.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Voltage Rating - DC | Voltage Rating - AC | Operating Temperature | Ratings | Approval Agency | Features | Mounting Type | Size / Dimension | Height (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
PMCU-6029CMC 1.3A 2LN TH |
1,000 | - |
|
Datasheet | - | Power Line | 2 | - | 3 mH @ 1 kHz | 1.3A | 260mOhm | - | 250V | -40°C ~ 80°C | - | - | - | - | - |
|
|
PMCU-4009CMC 750MA 2LN TH |
2,284 | - |
|
Datasheet | - | Power Line | 2 | - | 0.8 mH @ 1 kHz | 750mA | 220mOhm | - | 250V | -40°C ~ 80°C | - | - | - | - | - |
|
|
PMCU-7039CMC 2A 2LN TH |
1,000 | - |
|
Datasheet | - | Power Line | 2 | - | 0.9 mH @ 1 kHz | 2A | 120mOhm | - | 250V | -40°C ~ 80°C | - | - | - | - | - |
|
|
PMCE-0056CMC 2.25A 2LN TH |
1,840 | - |
|
Datasheet | - | Power Line | 2 | - | 5.6 mH @ 1 kHz | 2.25A | 80mOhm | - | 3750V (3.75kV) | -40°C ~ 80°C | - | - | - | - | - |
|
|
PMCU-8009CMC 1A 2LN TH |
1,000 | - |
|
Datasheet | - | Power Line | 2 | - | 10 mH @ 1 kHz | 1A | 520Ohm | 100V | 300V | -40°C ~ 80°C | - | - | - | - | - |
|
|
PMCU-2056CMC 1.4A 2LN TH |
2,446 | - |
|
Datasheet | - | Power Line | 2 | - | 5.6 mH @ 1 kHz | 1.4A | 150mOhm | - | 250V | -40°C ~ 80°C | - | - | - | - | - |
|
|
TSD-4547CMC 2LN TH |
150 | - |
|
Datasheet | - | - | 2 | - | - | - | - | - | 1000V (1kV) | 130°C | - | - | - | - | - |
|
|
TSD-4546CMC 2LN TH |
150 | - |
|
Datasheet | - | - | 2 | - | - | - | - | - | 2500V (2.5kV) | 130°C | - | - | - | - | - |
|
ACM2520-601-2P-T002CMC 300MA 2LN 600 OHM SMD |
768 | - |
|
Datasheet | Horizontal, 4 PC Pad | Signal Line | 2 | 600 Ohms @ 100 MHz | - | 300mA | 450mOhm | 20V | - | -40°C ~ 85°C | - | - | - | - | - |
|
ACM4520-142-2P-T000CMC 1.7A 2LN 1.4K OHM SMD |
516 | - |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | 1.4 kOhms @ 100 MHz | - | 1.7A | 80mOhm | 50V | - | -40°C ~ 85°C | - | - | - | - | - |
|
DR221-474AECMC 470UH 100MA 2LN SMD |
2,248 | - |
|
Datasheet | Horizontal, 4 Flat Lead | Signal Line | 2 | - | 470 µH @ 10 kHz | 100mA | 350mOhm | 50V | 100V | -40°C ~ 125°C | - | - | - | - | - |
|
CMS1-14-RCMC 205UH 850MA 2LN SMD |
4,353 | - |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | - | 205 µH @ 100 kHz | 850mA | 186mOhm (Typ) | - | - | -40°C ~ 160°C | - | - | - | - | - |
|
PA2757NLCMC 9A 2LN SMD |
4,140 | - |
|
Datasheet | Horizontal, 4 PC Pad | - | 2 | - | - | 9A | 9.75mOhm | - | - | -40°C ~ 130°C | - | - | - | - | - |
|
P0502NLCMC 14A 2LN SMD |
4,244 | - |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | - | - | 14A | 8mOhm | - | - | -40°C ~ 120°C | - | - | - | - | - |
|
TCK-053CMC 830UH 3.3A 2LN TH |
1,577 | - |
|
Datasheet | Horizontal, 4 PC Pin | - | 2 | - | 830 µH @ 100 kHz | 3.3A | 31mOhm | 500V | - | -40°C ~ 105°C | - | - | - | - | - |
|
|
P0502NLTCMC 14A 2LN SMD |
119 | - |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | - | - | 14A | 8mOhm | - | - | -40°C ~ 120°C | - | - | - | - | - |
|
B82722S0193A040CMC 380UH 19A 2LN SMD |
4,251 | - |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | - | 380 µH @ 100 kHz | 19A | 3mOhm | 80V | 48V | - | - | - | - | - | - |
|
8113-RCCMC 5MH 8.9A 2LN TH |
3,364 | - |
|
Datasheet | Vertical, 4 PC Pin | - | 2 | - | 5 mH @ 1 kHz | 8.9A | 22mOhm | - | - | -55°C ~ 105°C | - | - | - | - | - |
|
7448030333CMC 33MH 2.5A 2LN TH |
1,793 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 33 mH @ 10 kHz | 2.5A | 94mOhm | - | 300V | -55° C ~ 125°C | - | - | - | - | - |
|
8121-RCCMC 1MH 20A 2LN TH |
3,445 | - |
|
Datasheet | Vertical, 4 PC Pin | - | 2 | - | 1 mH @ 1 kHz | 20A | 7mOhm | - | - | -55°C ~ 105°C | - | - | - | - | - |
Common Mode Chokes FAQ
What Common Mode Chokes components can I source from EGOO?
You can browse available Common Mode Chokes product families, manufacturers and part numbers on this page, then review stock, datasheets and technical information for suitable options.
Can EGOO help with hard-to-source or obsolete Common Mode Chokes parts?
Yes. EGOO provides sourcing support for shortage, obsolete and hard-to-find electronic components. Send us the target manufacturer part number and quantity for checking.
Does EGOO support BOM and small-batch sourcing?
Yes. We support BOM sourcing, prototype requirements and small-batch supply, together with stock, lead-time and quotation assistance.
How do I request pricing and availability?
Submit the manufacturer part number, required quantity and any package, date-code or delivery requirements through the RFQ form, and our team will review available sourcing options.
