Common Mode Chokes
Browse available Common Mode Chokes components by manufacturer and part number. Review stock status, datasheets and key technical parameters to compare suitable options for design, maintenance, replacement or purchasing.
If you already have a target MPN or BOM, send it to EGOO with the required quantity. Our sourcing team can check availability, lead time and quotation options, including hard-to-find and obsolete parts.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Voltage Rating - DC | Voltage Rating - AC | Operating Temperature | Ratings | Approval Agency | Features | Mounting Type | Size / Dimension | Height (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SCF19XV-150-1R3A006JVCMC 440UH 15A 2LN TH AEC-Q200 |
214 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 440 µH @ 100 kHz | 15A | 2.91mOhm | 1000V (1kV) | 1000V (1kV) | -40°C ~ 150°C | AEC-Q200 | - | - | - | - |
|
SC-07-S045JHCMC 441UH 7A 3LN TH |
211 | - |
|
Datasheet | Horizontal, 6 PC Pin | Power Line | 3 | - | 441 µH @ 10 kHz | 7A | 13mOhm | 500V | 500V | -40°C ~ 120°C | - | - | - | - | - |
|
SC-15-20JHCMC 2MH 15A 2LN TH |
195 | - |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 2 mH @ 100 kHz | 15A | 12mOhm | 250V | 250V | -40°C ~ 105°C | - | - | - | - | - |
|
IHCM2321AAEG481N10CMC 480UH 8A 2LN 1.2K OHM SMD |
990 | - |
|
Datasheet | Horizontal, 4 Flat Lead | Power Line | 2 | 1.2 kOhms @ 10 MHz | 480 µH @ 100 kHz | 8A | 12.5mOhm | - | - | -40°C ~ 155°C | - | - | - | - | - |
|
T8008NLCMC 16LN SMD |
130 | - |
|
Datasheet | - | Signal Line | 16 | - | - | - | 400mOhm | - | - | - | - | - | - | - | - |
|
B82726S2203A020CMC 1.6MH 20A 2LN TH |
285 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 1.6 mH @ 10 kHz | 20A | 4.5mOhm (Typ) | - | 250V | -40°C ~ 125°C | - | - | - | - | - |
|
CMT908-H1CMC 2MH 7.5A 2LN TH ESD |
209 | - |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 2 mH @ 10 kHz | 7.5A | 20mOhm | - | 250V | - | - | - | - | - | - |
|
RT8122-6-10M0CMC 10MH 6A 2LN TH |
168 | - |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 10 mH @ 100 kHz | 6A | 33mOhm (Typ) | 425V | 300V | -40°C ~ 100°C | - | - | - | - | - |
|
SCR38-350-1R8B008JHCMC 850UH 35A 2LN TH |
457 | - |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 850 µH @ 10 kHz | 35A | 2.5mOhm | 250V | 250V | -25°C ~ 120°C | - | - | - | - | - |
|
7448041801CMC 1.5MH 18A 2LN TH |
228 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 1.5 mH @ 10 kHz | 18A | 3.2mOhm | - | 250V | -40°C ~ 125°C | - | - | - | - | - |
|
SCR25XV-170-1R7A009JHCMC 1MH 17A 2LN TH AEC-Q200 |
152 | - |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 1 mH @ 100 kHz | 17A | 3.83mOhm | 1000V (1kV) | 1000V (1kV) | -40°C ~ 120°C | AEC-Q200 | - | - | - | - |
|
RT8522-12-5M0CMC 5MH 12A 2LN TH |
322 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 5 mH @ 100 kHz | 12A | 14mOhm (Typ) | 425V | 300V | -40°C ~ 100°C | - | - | - | - | - |
|
SCR29XV-200-2R0A011JHCMC 740UH 20A 2LN TH AEC-Q200 |
230 | - |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 740 µH @ 100 kHz | 20A | 2.84mOhm | 1000V (1kV) | 1000V (1kV) | -40°C ~ 120°C | AEC-Q200 | - | - | - | - |
|
SCR29XV-050-1R0A044JVCMC 11.8MH 5A 2LN TH AEC-Q200 |
101 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 11.8 mH @ 100 kHz | 5A | 40.3mOhm | 1000V (1kV) | 1000V (1kV) | -40°C ~ 120°C | AEC-Q200 | - | - | - | - |
|
|
SCR29XV-070-1R2A030JVCMC 5.5MH 7A 2LN TH AEC-Q200 |
115 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 5.5 mH @ 100 kHz | 7A | 19.2mOhm | 1000V (1kV) | 1000V (1kV) | -40°C ~ 120°C | AEC-Q200 | - | - | - | - |
|
CM6296R-503CMC 50UH 10A 2LN SMD |
304 | - |
|
Datasheet | Horizontal, 4 PC Pad | - | 2 | - | 50 µH @ 1 kHz | 10A | 14mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
SC-30-100CMC 1MH 30A 2LN TH |
677 | - |
|
Datasheet | Horizontal, No Base, 4 PC Pin | Power Line | 2 | - | 1 mH @ 100 kHz | 30A | 6mOhm | 250V | 250V | -40°C ~ 105°C | - | - | - | - | - |
|
SCF25XV-310-2R3A004JVCMC 400UH 31A 2LN TH AEC-Q200 |
306 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 400 µH @ 100 kHz | 31A | 0.95mOhm | 1000V (1kV) | 1000V (1kV) | -40°C ~ 150°C | AEC-Q200 | - | - | - | - |
|
|
SCF25XV-070-1R1A022JVCMC 11.8MH 7A 2LN TH AEC-Q200 |
130 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 11.8 mH @ 100 kHz | 7A | 20.83mOhm | 1000V (1kV) | 1000V (1kV) | -40°C ~ 150°C | AEC-Q200 | - | - | - | - |
|
SCF25XV-220-1R9A007JHCMC 1.2MH 22A 2LN TH AEC-Q200 |
125 | - |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 1.2 mH @ 100 kHz | 22A | 2.45mOhm | 1000V (1kV) | 1000V (1kV) | -40°C ~ 150°C | AEC-Q200 | - | - | - | - |
Common Mode Chokes FAQ
What Common Mode Chokes components can I source from EGOO?
You can browse available Common Mode Chokes product families, manufacturers and part numbers on this page, then review stock, datasheets and technical information for suitable options.
Can EGOO help with hard-to-source or obsolete Common Mode Chokes parts?
Yes. EGOO provides sourcing support for shortage, obsolete and hard-to-find electronic components. Send us the target manufacturer part number and quantity for checking.
Does EGOO support BOM and small-batch sourcing?
Yes. We support BOM sourcing, prototype requirements and small-batch supply, together with stock, lead-time and quotation assistance.
How do I request pricing and availability?
Submit the manufacturer part number, required quantity and any package, date-code or delivery requirements through the RFQ form, and our team will review available sourcing options.
