FET, MOSFET Arrays
Compare the current FET, MOSFET Arrays FETs, MOSFETs selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Configuration | FET Feature | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Input Capacitance (Ciss) (Max) @ Vds | Power - Max | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DMN2991UDA-7BMOSFET 2N-CH 20V 0.45A 6DFN |
55,501 | - |
|
Datasheet | - | 6-SMD, No Lead | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 20V | 450mA (Ta) | 990mOhm @ 100mA, 4.5V | 1V @ 250µA | 0.35nC @ 4.5V | 21.5pF @ 16V | 310mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | X2-DFN0806-6 |
|
DMN32D4SDW-7MOSFET 2N-CH 30V 0.65A SOT363 |
16,388 | - |
|
Datasheet | - | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 30V | 650mA | 400mOhm @ 250mA, 10V | 1.6V @ 250µA | 1.3nC @ 10V | 50pF @ 15V | 290mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-363 |
|
|
DMG1016UDWQ-7MOSFET N/P-CH 20V 1.066A SOT363 |
6,000 | - |
|
Datasheet | - | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Not For New Designs | MOSFET (Metal Oxide) | N and P-Channel Complementary | - | 20V | 1.066A (Ta), 845mA (Ta) | 450mOhm @ 600mA, 4.5V, 750mOhm @ 430mA, 4.5V | 1V @ 250µA | 736.6nC @ 4.5V, 0.62nC @ 4.5V | 60.67pF @ 10V, 59.76pF @ 16V | 330mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-363 |
|
|
2N7002DWQ-13-FMOSFET 2N-CH 60V 0.23A SOT363 |
9,680 | - |
|
Datasheet | - | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 60V | 230mA (Ta) | 7.5Ohm @ 50mA, 5V | 2V @ 250µA | - | 50pF @ 25V | 310mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-363 |
|
DMN601VKQ-7MOSFET 2N-CH 60V 0.305A SOT563 |
2,390 | - |
|
Datasheet | - | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 60V | 305mA | 2Ohm @ 500mA, 10V | 2.5V @ 250µA | - | 50pF @ 25V | 250mW | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-563 |
|
|
DMN53D0LV-7MOSFET 2N-CH 50V 0.35A SOT563 |
81,830 | - |
|
Datasheet | - | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 50V | 350mA (Ta) | 1.6Ohm @ 500mA, 10V | 1.5V @ 250µA | 0.6nC @ 4.5V | 46pF @ 25V | 430mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-563 |
|
|
DMP56D0UV-7MOSFET 2P-CH 50V 0.16A SOT563 |
4,431 | - |
|
Datasheet | - | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | Logic Level Gate | 50V | 160mA | 6Ohm @ 100mA, 4V | 1.2V @ 250µA | 0.58nC @ 4V | 50.54pF @ 25V | 400mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-563 |
|
DMC3730UFL3-7MOSFET N/P-CH 30V 6DFN |
7,629 | - |
|
Datasheet | - | 6-XFDFN Exposed Pad | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel Complementary | - | 30V | 1.1A, 700mA | 460mOhm @ 200mA, 4.5V | 950mV @ 250µA | 0.9nC @ 4.5V | 65.9pF @ 25V | 390mW | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | X2-DFN1310-6 (Type B) |
|
DMP2200UFCL-7MOSFET 2P-CH 20V 1.7A 6UDFN |
2,232 | - |
|
Datasheet | - | 6-UFDFN Exposed Pad | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | - | 20V | 1.7A | 200mOhm @ 2A, 4.5V | 1.2V @ 250µA | 2.2nC @ 4.5V | 184pF @ 10V | 660mW | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | U-DFN1616-6 (Type F) |
|
DMC2038LVTQ-7MOSFET N/P-CH 20V 3.7A TSOT23-6 |
15,410 | - |
|
Datasheet | - | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Not For New Designs | MOSFET (Metal Oxide) | N and P-Channel Complementary | Logic Level Gate, 1.8V Drive | 20V | 3.7A (Ta), 2.6A (Ta) | 35mOhm @ 4A, 4.5V, 74mOhm @ 3A, 4.5V | 1V @ 250µA | 5.7nC @ 4.5V, 10nC @ 4.5V | 530pF @ 10V, 705pF @ 10V | 800mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TSOT-23-6 |
