Fixed Inductors
Browse available Fixed Inductors components by manufacturer and part number. Review stock status, datasheets and key technical parameters to compare suitable options for design, maintenance, replacement or purchasing.
If you already have a target MPN or BOM, send it to EGOO with the required quantity. Our sourcing team can check availability, lead time and quotation options, including hard-to-find and obsolete parts.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CC453232-1R8KLFIXED IND 1.8UH 900MA 160MOHM SM |
1,984 | - |
|
Datasheet | CC453232 | 1812 (4532 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 1.8 µH | ±10% | 900 mA | - | Unshielded | 160mOhm Max | 10 @ 7.96MHz | 100MHz | - | -40°C ~ 125°C | 7.96 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
AWVF00303015330M00INDUCTOR POWER |
1,978 | - |
|
Datasheet | AWVF | 1212 (3030 Metric) | Tape & Reel (TR) | Active | - | Ferrite | 33 µH | ±20% | 600 mA | 650mA | Shielded | 930mOhm | - | - | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1212 | 0.118" L x 0.118" W (3.00mm x 3.00mm) | 0.059" (1.50mm) |
|
|
AWVF003030123R3M00INDUCTOR POWER |
1,975 | - |
|
Datasheet | AWVF | 1212 (3030 Metric) | Tape & Reel (TR) | Active | - | Ferrite | 3.3 µH | ±20% | 1.8 A | 1.84A | Shielded | 130mOhm | - | - | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1212 | 0.118" L x 0.118" W (3.00mm x 3.00mm) | 0.047" (1.20mm) |
|
BWVN00322515100M00INDUCTOR POWER |
1,950 | - |
|
Datasheet | BWVN | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 10 µH | ±20% | 700 mA | 750mA | Unshielded | 380mOhm | - | - | - | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.067" (1.70mm) |
|
LSCNA1608FKTR47MAFIXED IND 470NH 1.9A 85 MOHM SMD |
1,490 | - |
|
Datasheet | LSCN | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Multilayer | Metal | 470 nH | ±20% | 1.6 A | 1.9A | Unshielded | 85mOhm Max | - | - | - | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 0603 | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.024" (0.60mm) |
|
F1C1-252012-100MFIXED IND 10.0 UH 1.05A 400 MOHM |
12,000 | - |
|
Datasheet | F1C1-2520 | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Molded | Metal | 10 µH | ±20% | 1.05 A | 1.45A | Shielded | 400mOhm Max | - | - | - | -55°C ~ 125°C | 1 MHz | - | Surface Mount | 1008 | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.047" (1.20mm) |
|
ASMPM-0806-1R0M-TFIXED IND 1UH 2.6A 70 MOHM SMD |
11,662 | - |
|
Datasheet | ASMPM | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 1 µH | ±20% | 2.6 A | 3.1A | Unshielded | 70mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 0806 (2016 Metric) | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.039" (1.00mm) |
|
B78148S1474J000FIXED IND 470UH 170MA 7.9 OHM TH |
11,135 | - |
|
Datasheet | BC | Radial | Tape & Reel (TR) | Active | Wirewound | - | 470 µH | ±5% | 170 mA | - | Unshielded | 7.9Ohm Max | 70 @ 796kHz | 2.2MHz | - | - | 796 kHz | - | Through Hole | - | 0.157" Dia x 0.362" L (4.00mm x 9.20mm) | - |
|
|
ASMPM-0806-4R7M-TFIXED IND 4.7UH 1.1A 360MOHM SMD |
9,695 | - |
|
Datasheet | ASMPM | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 4.7 µH | ±20% | 1.1 A | 1.3A | Unshielded | 360mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 0806 (2016 Metric) | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.039" (1.00mm) |
|
|
ASMPM-0806-1R5M-TFIXED IND 1.5UH 2.1A 110MOHM SMD |
7,665 | - |
|
Datasheet | ASMPM | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 1.5 µH | ±20% | 2.1 A | 2.5A | Unshielded | 110mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 0806 (2016 Metric) | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.039" (1.00mm) |
|
PM1210-330J-RCFIXED IND 33UH 85MA 5.6 OHM SMD |
7,180 | - |
|
Datasheet | PM1210 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±5% | 85 mA | - | Unshielded | 5.6Ohm Max | 30 @ 2.52MHz | 20MHz | - | -40°C ~ 125°C | 2.52 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
LSXBD4040TKL470MFIXED IND 47UH 420MA 780MOHM SMD |
7,000 | - |
|
Datasheet | LSXB | Nonstandard | Tape & Reel (TR) | Not For New Designs | Wirewound | Ferrite | 47 µH | ±20% | 420 mA | 570mA | Shielded | 650mOhm | - | 10MHz | - | -25°C ~ 120°C | 100 kHz | - | Surface Mount | - | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.071" (1.80mm) |
|
LSXBD4040TKL220MFIXED IND 22UH 590MA 432MOHM SMD |
6,050 | - |
|
Datasheet | LSXB | Nonstandard | Tape & Reel (TR) | Not For New Designs | Wirewound | Ferrite | 22 µH | ±20% | 590 mA | 800mA | Shielded | 360mOhm | - | 16MHz | - | -25°C ~ 120°C | 100 kHz | - | Surface Mount | - | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.071" (1.80mm) |
|
|
SRN3012BTA-R47MFIXED IND 470NH 5.2A 0.029OHM SM |
6,000 | - |
|
Datasheet | SRN3012BTA | 1212 (3030 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 470 nH | ±20% | 5.2 A | 4.8A | Shielded | 29mOhm Max | 10 @ 1MHz | 190MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 3012 | 0.118" L x 0.118" W (3.00mm x 3.00mm) | 0.047" (1.20mm) |
|
LQH2HNH120J03LFIXED IND 12UH 140MA POWRTRN |
5,866 | - |
|
Datasheet | LQH2 | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 12 µH | ±5% | 140 mA | - | Shielded | 1.3Ohm | - | 27MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1008 | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.039" (1.00mm) |
|
|
LQH2HNHR82K03LFIXED IND 0.82UH 550MA POWRTRN |
5,740 | - |
|
Datasheet | LQH2 | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 820 nH | ±10% | 550 mA | - | Shielded | 90mOhm | - | 180MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1008 | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.039" (1.00mm) |
|
|
SRN3012BTA-4R7MFIXED IND 4.7UH 2.1A 0.168OHM SM |
5,299 | - |
|
Datasheet | SRN3012BTA | 1212 (3030 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 4.7 µH | ±20% | 2.1 A | 1.5A | Shielded | 168mOhm Max | 10 @ 1MHz | 60MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 3012 | 0.118" L x 0.118" W (3.00mm x 3.00mm) | 0.047" (1.20mm) |
|
|
B78148S1222J000FIXED IND 2.2UH 1A 250 MOHM TH |
4,000 | - |
|
Datasheet | BC | Radial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 2.2 µH | ±5% | 1 A | - | Unshielded | 250mOhm Max | 55 @ 7.96MHz | 140MHz | - | -55°C ~ 125°C | 7.96 MHz | - | Through Hole | - | 0.157" Dia x 0.362" L (4.00mm x 9.20mm) | - |
|
|
B78148S1104J000FIXED IND 100UH 370MA 1.7 OHM TH |
3,618 | - |
|
Datasheet | BC | Radial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 100 µH | ±5% | 370 mA | - | Unshielded | 1.7Ohm Max | 70 @ 796kHz | 5MHz | - | -55°C ~ 125°C | 796 kHz | - | Through Hole | - | 0.157" Dia x 0.362" L (4.00mm x 9.20mm) | - |
|
LQM2MPNR47MGHLFIXED IND 470NH 2.5A 46 MOHM SMD |
3,592 | - |
|
Datasheet | LQM2 | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Multilayer | Ferrite | 470 nH | ±20% | 2.5 A | 3.4A | Shielded | 46mOhm Max | - | 80MHz | - | -40°C ~ 85°C | 1 MHz | - | Surface Mount | 0806 (2016 Metric) | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.039" (1.00mm) |
Fixed Inductors FAQ
What Fixed Inductors components can I source from EGOO?
You can browse available Fixed Inductors product families, manufacturers and part numbers on this page, then review stock, datasheets and technical information for suitable options.
Can EGOO help with hard-to-source or obsolete Fixed Inductors parts?
Yes. EGOO provides sourcing support for shortage, obsolete and hard-to-find electronic components. Send us the target manufacturer part number and quantity for checking.
Does EGOO support BOM and small-batch sourcing?
Yes. We support BOM sourcing, prototype requirements and small-batch supply, together with stock, lead-time and quotation assistance.
How do I request pricing and availability?
Submit the manufacturer part number, required quantity and any package, date-code or delivery requirements through the RFQ form, and our team will review available sourcing options.
