Fixed Inductors
Compare the current Fixed Inductors Inductors, Coils, Chokes selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1140-100K-RCFIXED IND 10UH 21.8A 5 MOHM TH |
2,139 | - |
|
Datasheet | 1140 | Radial | Bulk | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±10% | 21.8 A | 65.3A | Unshielded | 5mOhm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.500" Dia (38.10mm) | 1.030" (26.16mm) |
|
|
1140-4R7M-RCFIXED IND 4.7UH 28.1A 3 MOHM TH |
4,399 | - |
|
Datasheet | 1140 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 4.7 µH | ±20% | 28.1 A | 80A | Unshielded | 3mOhm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.500" Dia (38.10mm) | 1.030" (26.16mm) |
|
CI160808-6N8JFIXED IND 6.8NH 300MA 300MOHM SM |
199 | - |
|
Datasheet | CI160808 | 0603 (1608 Metric) | Tape & Reel (TR) | Not For New Designs | Multilayer | Ceramic | 6.8 nH | ±5% | 300 mA | - | Unshielded | 300mOhm Max | 10 @ 100MHz | 2.6GHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.037" (0.95mm) |
|
SRN6028-3R9MFIXED IND 3.9UH 3A 38 MOHM SMD |
2,661 | - |
|
Datasheet | SRN6028 | 2424 (6060 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 3.9 µH | ±20% | 3 A | 2.7A | Shielded | 38mOhm Max | 10 @ 7.96MHz | 35MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 6028 | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.110" (2.80mm) |
.JPG "CW105550A-4N7J")
|
CW105550A-4N7JFIXED IND 4.7NH 640MA 130MOHM SM |
301 | - |
|
Datasheet | CW105550A | 0402 (1005 Metric) | Tape & Reel (TR) | Active | - | Ceramic | 4.7 nH | ±5% | 640 mA | - | Unshielded | 130mOhm Max | 15 @ 250MHz | 4.775GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | 0.024" (0.60mm) |
|
|
CW105550A-13NJFIXED IND 13NH 560MA 210MOHM SMD |
273 | - |
|
Datasheet | CW105550A | 0402 (1005 Metric) | Tape & Reel (TR) | Active | - | Ceramic | 13 nH | ±5% | 560 mA | - | Unshielded | 210mOhm Max | 24 @ 250MHz | 3.45GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | 0.024" (0.60mm) |
.JPG "CW161009A-24NJ")
|
CW161009A-24NJFIXED IND 24NH 700MA 140MOHM SMD |
135 | - |
|
Datasheet | CW161009A | 0603 (1608 Metric) | Tape & Reel (TR) | Active | - | Ceramic | 24 nH | ±5% | 700 mA | - | Unshielded | 140mOhm Max | 35 @ 250MHz | 2.65GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.065" L x 0.045" W (1.65mm x 1.15mm) | 0.043" (1.10mm) |
|
|
CW161009A-R27JFIXED IND 270NH 200MA 2.1OHM SMD |
122 | - |
|
Datasheet | CW161009A | 0603 (1608 Metric) | Tape & Reel (TR) | Active | - | Ceramic | 270 nH | ±5% | 200 mA | - | Unshielded | 2.1Ohm Max | 25 @ 100MHz | 822MHz | AEC-Q200 | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0603 | 0.065" L x 0.045" W (1.65mm x 1.15mm) | 0.043" (1.10mm) |
|
|
CW105550A-12NJFIXED IND 12NH 640MA 120MOHM SMD |
110 | - |
|
Datasheet | CW105550A | 0402 (1005 Metric) | Tape & Reel (TR) | Active | - | Ceramic | 12 nH | ±5% | 640 mA | - | Unshielded | 120mOhm Max | 26 @ 250MHz | 3.6GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | 0.024" (0.60mm) |
|
SRN3030HA-470MIND,3X3X3MM,47UH20%,0.35A,150C,S |
680 | - |
|
Datasheet | SRN3030HA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±20% | 350 mA | 750mA | Shielded | 2.05Ohm Max | 27 @ 2.52MHz | 10MHz | AEC-Q200 | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.118" L x 0.118" W (3.00mm x 3.00mm) | 0.118" (3.00mm) |
Fixed Inductors FAQ
How can I narrow the current Fixed Inductors selection?
Use the available manufacturer and technical filters to compare matching parts by specifications, stock status, pricing and datasheet information.
Can EGOO help source hard-to-find or obsolete Fixed Inductors parts?
Yes. Send the manufacturer part number and required quantity to our sourcing team for availability, lead-time and alternative sourcing support.
Can I request a quotation for a BOM or small-batch requirement?
Yes. EGOO supports BOM sourcing, prototype quantities and small-batch purchasing. Provide your part list and quantities for a quotation review.
What information should I provide when requesting a quote?
Please provide the target part number, manufacturer, quantity and any required date code, package or delivery requirements so our team can respond more accurately.
