IGBT Modules
Compare the current IGBT Modules IGBTs selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | IGBT Type | Configuration | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Power - Max | Vce(on) (Max) @ Vge, Ic | Current - Collector Cutoff (Max) | Input Capacitance (Cies) @ Vce | Input | NTC Thermistor | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FZ2400R17HP4HOSA2IGBT MODULE 1700V 400A |
2 | - |
|
Datasheet | IHM-B | Module | Tray | Active | - | Single Switch | 1700 V | 2400 A | 15500 W | 2.25V @ 15V, 2.4kA | 5 mA | 195 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | - |
|
FZ1600R17HP4B2BOSA2IGBT MODULE 1700V 1600A |
10 | - |
|
Datasheet | IHM-B | Module | Tray | Active | Trench Field Stop | Single Switch | 1700 V | 1600 A | 10500 W | 2.25V @ 15V, 1.6kA | 5 mA | 130 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | A-IHV130-3 |
|
|
FZ1200R17HP4B2BOSA2IGBT MOD 1700V 1200A 7800W |
2 | - |
|
Datasheet | IHM-B | Module | Tray | Active | Trench Field Stop | Half Bridge | 1700 V | 1200 A | 7800 W | 2.25V @ 15V, 1200A | 5 mA | 97 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount | Module |
|
FZ250R65KE3NPSA1IGBT MOD 6500V 500A 4800W |
4 | - |
|
Datasheet | - | Module | Tray | Active | - | Single | 6500 V | 500 A | 4800 W | 3.4V @ 15V, 250A | 5 mA | 69 nF @ 25 V | Standard | No | -50°C ~ 125°C | Chassis Mount | Module |
|
FS25R12W1T4BOMA1IGBT MOD 1200V 45A 205W |
11 | - |
|
Datasheet | - | Module | Bulk | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 45 A | 205 W | 2.25V @ 15V, 25A | 1 mA | 1.45 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
DDB6U75N16W1RBOMA1IGBT MOD 1200V 69A 335W |
24 | - |
|
Datasheet | - | Module | Tray | Active | - | Three Phase Inverter | 1200 V | 69 A | 335 W | 2.15V @ 15V, 50A | 1 mA | 2.8 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
FP15R12W1T4B3BOMA1IGBT MOD 1200V 28A 130W |
45 | - |
|
Datasheet | EasyPIM™ | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 28 A | 130 W | 2.25V @ 15V, 15A | 1 mA | 890 pF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
|
FP10R12W1T4B11BOMA1IGBT MOD 1200V 20A 105W |
7 | - |
|
Datasheet | EconoPIM™ 3 | Module | Tray | Active | - | Three Phase Inverter | 1200 V | 20 A | 105 W | 2.25V @ 15V, 10A | 1 mA | 600 pF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
|
FP15R12W1T4B11BOMA1IGBT MOD 1200V 28A 130W |
11 | - |
|
Datasheet | - | Module | Tray | Active | - | Three Phase Inverter | 1200 V | 28 A | 130 W | 2.25V @ 15V, 15A | 1 mA | 890 pF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
FS50R12W2T4BOMA1IGBT MOD 1200V 83A 335W |
51 | - |
|
Datasheet | EasyPACK™ | Module | Tray | Active | Trench Field Stop | Full Bridge Inverter | 1200 V | 83 A | 335 W | 2.15V @ 15V, 50A | 1 mA | 2.8 nF @ 25 V | Standard | Yes | -40°C ~ 125°C | Chassis Mount | Module |
