Power Relays, Over 2 Amps
Browse available Power Relays, Over 2 Amps components by manufacturer and part number. Review stock status, datasheets and key technical parameters to compare suitable options for design, maintenance, replacement or purchasing.
If you already have a target MPN or BOM, send it to EGOO with the required quantity. Our sourcing team can check availability, lead time and quotation options, including hard-to-find and obsolete parts.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Coil Voltage | Contact Form | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Coil Current | Coil Type | Features | Termination Style | Seal Rating | Coil Insulation | Must Operate Voltage | Must Release Voltage | Operate Time | Release Time | Operating Temperature | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MK2KP AC120RELAY GEN PURPOSE DPDT 5A 120V |
2,311 | - |
|
Datasheet | MKK | Bulk | Obsolete | Socketable | 120VAC | DPDT (2 Form C) | 5 A | 250VAC, 250VDC - Max | 1100VA, 72W | 19 mA | Latching, Dual Coil | - | Plug In, 11 Pin (Octal) | - | - | 96 VAC | - | 30 ms | 30 ms | -10°C ~ 40°C | Silver (Ag) | General Purpose | - | - |
|
|
3TX71300RC03OPEN RELAY, DPDT, MAG BLO, 40A, |
4,788 | - |
|
Datasheet | - | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
3TX71300RF03OPEN RELAY, DPDT, MAG BLO, 40A, |
4,006 | - |
|
Datasheet | - | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
3TX71300RF13OPEN RELAY, DPDT, MAG BLO, 40A, |
4,669 | - |
|
Datasheet | - | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
3TX71300RD03OPEN RELAY, DPDT, MAG BLO, 40A, |
2,327 | - |
|
Datasheet | - | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
3TX71300RB03OPEN RELAY, DPDT, MAG BLO, 40A, |
4,630 | - |
|
Datasheet | - | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
MGN1X-AC480RELAY GEN PURPOSE SPST 30A 480V |
3,166 | - |
|
Datasheet | MGN | Bulk | Active | Chassis Mount | 480VAC | SPST-NO (DM) (1 Form X) | 30 A | 600VAC, 28VDC - Max | 18000VA, 840W | 20 mA | Non Latching | - | Screw Terminal | - | Class F | 408 VAC | - | 30 ms | 30 ms | -45°C ~ 80°C | - | General Purpose | - | - |
|
MGN2AM-DC48RELAY GEN PURPOSE DPST 30A 48V |
4,943 | - |
|
Datasheet | MGN | Bulk | Active | Chassis Mount | 48VDC | DPST-NO (2 Form A) | 30 A | 600VAC, 28VDC - Max | 18000VA, 840W | 41.6 mA | Non Latching | - | Screw Terminal | - | Class F | 36 VDC | - | 30 ms | 30 ms | -40°C ~ 115°C | - | General Purpose | - | - |
|
ARA-24-ACARELAY GEN PURPOSE DPDT 10A 24V |
2,215 | - |
|
Datasheet | ARA | Box | Discontinued at Digi-Key | Socketable | 24VAC/DC | DPDT (2 Form C) | 10 A | 240VAC - Nom | - | - | Non Latching | Lighted Indicator | Plug In, 8 Pin (Octal) | - | - | - | - | - | - | -20°C ~ 55°C | - | General Purpose | - | - |
|
|
3-1393806-4RELAY GEN PURPOSE DPST 5A 1.1V |
3,249 | - |
|
Datasheet | V23154, AXICOM | Bulk | Active | Socketable | 1.1VDC | DPST-NO/NC (1 Form A, 1 Form B) | 5 A | 250VAC, 250VDC - Max | - | 16.7 mA | Non Latching | - | Plug In | - | - | 0.4 VDC | - | 7.5 ms | 3 ms | -40°C ~ 70°C | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
ALT230-X-SWRELAY IMPULSE DPDT 230V |
4,601 | - |
|
Datasheet | - | Bulk | Active | Socketable | 230VAC | DPDT (2 Form C) | - | 240VAC - Nom | - | - | Latching, Single Coil | Debounce Delay | Plug In, 8 Pin (Octal) | - | - | - | - | - | - | -40°C ~ 50°C | - | Impulse | - | - |
|
|
MM3P DC125RELAY GEN PURPOSE 3PDT 7.5A 125V |
4,256 | - |
|
Datasheet | MM | Bulk | Active | Socketable | 125VDC | 3PDT (3 Form C) | 7.5 A | 250VAC, 250VDC - Max | 1700VA, 120W | 21.6 mA | Non Latching | - | Plug In, 15 Pin (Octal) | - | - | 87.5 VDC | 12.5 VDC | 50 ms | 30 ms | -10°C ~ 55°C | Silver (Ag) | General Purpose | - | - |
|
|
MM3XP DC48RELAY GEN PURPOSE 3PDT 7A 48V |
2,478 | - |
|
Datasheet | MM | Bulk | Active | Socketable | 48VDC | 3PDT (3 Form C) | 7.5 A | 250VAC, 250VDC - Max | 20VA, 800W | 52 mA | Non Latching | - | Plug In, 15 Pin (Octal) | - | - | 33.6 VDC | 4.8 VDC | 50 ms | 30 ms | -10°C ~ 55°C | Silver (Ag) | General Purpose | - | - |
|
|
MM2XPN AC200/(220)RELAY GEN PURPOSE DPDT 7A 220V |
2,625 | - |
|
Datasheet | MM | Bulk | Active | Socketable | 220VAC | DPDT (2 Form C) | 7.5 A | 250VAC, 250VDC - Max | 20VA, 800W | 17.5 mA | Non Latching | Lighted Indicator | Plug In, 8 Pin (Octal) | - | - | 176 VAC | 66 VAC | 25 ms | 30 ms | -10°C ~ 55°C | Silver (Ag) | General Purpose | - | - |
|
|
1447610000RSM-4 230VAC 1CO Z |
4,689 | - |
|
Datasheet | RSM | Box | Active | DIN Rail | 230VAC | SPDT (1 Form C) x 4 | 6 A | 250VAC - Max | 1500VA | 3.3 mA | Non Latching | Lighted Indicator | Spring Terminal | - | - | - | - | - | - | -25°C ~ 50°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
S89R11DPP1-24RELAY IMPULSE SPDT 15A 24V |
2,569 | - |
|
Datasheet | S89R | Bulk | Obsolete | Socketable | 24VDC | SPDT (1 Form C) | 15 A | 277VAC - Max | 4155VA | 260.9 mA | Latching, Single Coil | - | Plug In, 8 Pin (Octal) | - | Class B | 18 VDC | - | - | - | -10°C ~ 60°C | - | Impulse | - | - |
|
|
KB-17AY-120RELAY GEN PURPOSE 4PDT 5A 120V |
1,781 | - |
|
Datasheet | KB | Bulk | Obsolete | Chassis Mount | 120VAC | 4PDT (4 Form C) | 5 A | 120VAC - Nom | - | 44 mA | Latching, Dual Coil | - | Solder Lug | - | - | 102 VAC | - | - | - | -45°C ~ 85°C | Silver (Ag) | General Purpose | - | - |
|
|
1457380000RSM-8 24V+ BASE Z |
4,198 | - |
|
Datasheet | RSM | Box | Active | DIN Rail | 24VDC | SPDT (1 Form C) x 8 | 6 A | 250VAC - Max | 1500VA | 16.7 mA | Non Latching | Lighted Indicator | Spring Terminal | - | - | - | - | - | - | -25°C ~ 50°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
1447570000RSM-4 115VAC/DC 1CO S |
2,648 | - |
|
Datasheet | RSM | Box | Active | DIN Rail | 115VAC/DC | SPDT (1 Form C) x 4 | 6 A | 250VAC - Max | 1500VA | 3.3 mA | Non Latching | Lighted Indicator | Screw Terminal | - | - | - | - | - | - | -25°C ~ 50°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
286-307/004-000RELAY GEN PURPOSE SPDT 3A 110V |
3,645 | - |
|
Datasheet | 286 | Box | Active | Socketable | 110VDC | SPDT (1 Form C) | 3 A | 250VAC - Max | 750VA | 3.1 mA | Non Latching | Lighted Indicator | Plug In | - | - | - | - | 8 ms | 6 ms | -25°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
Power Relays, Over 2 Amps FAQ
What Power Relays, Over 2 Amps components can I source from EGOO?
You can browse available Power Relays, Over 2 Amps product families, manufacturers and part numbers on this page, then review stock, datasheets and technical information for suitable options.
Can EGOO help with hard-to-source or obsolete Power Relays, Over 2 Amps parts?
Yes. EGOO provides sourcing support for shortage, obsolete and hard-to-find electronic components. Send us the target manufacturer part number and quantity for checking.
Does EGOO support BOM and small-batch sourcing?
Yes. We support BOM sourcing, prototype requirements and small-batch supply, together with stock, lead-time and quotation assistance.
How do I request pricing and availability?
Submit the manufacturer part number, required quantity and any package, date-code or delivery requirements through the RFQ form, and our team will review available sourcing options.
