Angle, Linear Position Measuring
Compare the current Angle, Linear Position Measuring Position Sensors selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Programmable | For Measuring | Technology | Rotation Angle - Electrical, Mechanical | Linear Range | Output | Output Signal | Actuator Type | Linearity | Resistance | Resistance Tolerance | Voltage - Supply | Mounting Type | Termination Style | Operating Temperature | Grade | Qualification | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
3048L-4-502SENSOR LINEAR 10.16MM WIRE LEADS |
3,686 | - |
|
Datasheet | Module, Wire Leads, Threaded | - | Tray | Active | - | Linear Position | Resistive | - | 0 ~ 10.16mm (0 ~ 0.40") | Resistive | - | Round Shaft | ±5% | 5 kOhms | ±20% | - | Chassis Mount | Wire Leads | -55°C ~ 125°C | - | - | - |
|
AMS22S5A1BHBFL336SENSOR ROTARY 360DEG SOLDER LUG |
3,671 | - |
|
Datasheet | Module, Flatted Shaft | AMS22S | Tray | Active | - | Rotary Position | Hall Effect | 10° ~ 360°, Continuous | - | Analog Voltage | Clockwise Increase | Flatted Shaft | ±0.5% | - | - | 5V | Panel Mount | Solder Lug | -40°C ~ 125°C | - | - | - |
|
AMS22B5A1BLASL334SSENSOR ROTARY 340DEG SOLDER LUG |
4,136 | - |
|
Datasheet | Module, Slotted Shaft | AMS22B | Tray | Active | - | Rotary Position | Hall Effect | 10° ~ 340°, Continuous | - | Analog Voltage | Clockwise Increase | Slotted Shaft | ±0.5% | - | - | 5V | Panel Mount | Solder Lug | -40°C ~ 125°C | - | - | - |
|
3382H-2-502SENSOR ROTARY 330DEG PC PIN |
3,123 | - |
|
Datasheet | Module, PC Pins | - | Tube | Active | - | Rotary Position | Resistive | 0° ~ 330°, Continuous | - | Resistive | Clockwise Increase | Hole for Shaft | ±2% | 5 kOhms | ±30% | - | Through Hole | PC Pin | -40°C ~ 120°C | - | - | - |
|
|
3382H-1-253SENSOR ROTARY 330DEG PC PIN |
3,985 | - |
|
Datasheet | Module, PC Pins | - | Tube | Active | - | Rotary Position | Resistive | 0° ~ 330°, Continuous | - | Resistive | Clockwise Increase | Hole for Shaft | ±2% | 25 kOhms | ±30% | - | Through Hole | PC Pin | -40°C ~ 120°C | - | - | - |
|
3046L-1-102SENSOR LINEAR 3.81MM WIRE LEADS |
2,299 | - |
|
Datasheet | Module, Wire Leads, Threaded | - | Tray | Active | - | Linear Position | Resistive | - | 0 ~ 3.81mm (0 ~ 0.15") | Resistive | - | Round Shaft | ±5% | 1 kOhms | ±20% | - | Chassis Mount | Wire Leads | -55°C ~ 125°C | - | - | - |
|
|
3046L-1-203SENSOR LINEAR 3.81MM WIRE LEADS |
1,724 | - |
|
Datasheet | Module, Wire Leads, Threaded | - | Tray | Active | - | Linear Position | Resistive | - | 0 ~ 3.81mm (0 ~ 0.15") | Resistive | - | Round Shaft | ±5% | 20 kOhms | ±20% | - | Chassis Mount | Wire Leads | -55°C ~ 125°C | - | - | - |
|
|
3046L-3-102SENSOR LINEAR 8.89MM WIRE LEADS |
4,583 | - |
|
Datasheet | Module, Wire Leads, Threaded | - | Tray | Active | - | Linear Position | Resistive | - | 0 ~ 8.89mm (0 ~ 0.35") | Resistive | - | Round Shaft | ±5% | 1 kOhms | ±20% | - | Chassis Mount | Wire Leads | -55°C ~ 125°C | - | - | - |
|
AMM20B5A1CLASL380SENSOR ROTARY 3960DEG PC PIN |
1,302 | - |
|
Datasheet | Module, Slotted Shaft | AMM20B | Tray | Active | - | Rotary Position | Hall Effect | 0° ~ 3600°, 0° ~ 3960° | - | Analog Voltage | Clockwise Increase | Slotted Shaft | ±0.3% | - | - | 5V | Panel Mount | PC Pin | -40°C ~ 125°C | - | - | - |
|
3048L-2-503SENSOR LINEAR 5.08MM WIRE LEADS |
3,827 | - |
|
Datasheet | Module, Wire Leads, Threaded | - | Tray | Active | - | Linear Position | Resistive | - | 0 ~ 5.08mm (0 ~ 0.20") | Resistive | - | Round Shaft | ±5% | 50 kOhms | ±20% | - | Chassis Mount | Wire Leads | -55°C ~ 125°C | - | - | - |
