Film Capacitors
Compare the current Film Capacitors Capacitors selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Capacitance | Tolerance | Voltage Rating - AC | Voltage Rating - DC | Dielectric Material | ESR (Equivalent Series Resistance) | Operating Temperature | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination | Lead Spacing | Applications | Ratings | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Series Straight 23x17.jpg "ECW-F2685JA")
|
ECW-F2685JACAP FILM 6.8UF 5% 250VDC RADIAL |
742 | - |
|
Datasheet | Radial | 6.8 µF | ±5% | 125V | 250V | Polypropylene (PP), Metallized | - | -40°C ~ 105°C | Through Hole | 0.937" L x 0.701" W (23.80mm x 17.80mm) | 0.984" (25.00mm) | PC Pins | 0.787" (20.00mm) | High Frequency, Switching | - | - |
|
EZP-V1B405LTTCAP FILM 4UF 10% 1100V RADIAL |
318 | - |
|
Datasheet | Radial | 4 µF | ±10% | - | 1100V (1.1kV) | Polypropylene (PP), Metallized | 23.5 mOhms | -40°C ~ 105°C | Through Hole | 1.614" L x 0.591" W (41.00mm x 15.00mm) | 1.181" (30.00mm) | PC Pins | 1.476" (37.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | Long Life, Low ESR |
|
EZP-Q33405LTACAP FILM 4UF 5% 330VAC RADIAL |
261 | - |
|
Datasheet | Radial | 4 µF | ±5% | 330V | - | Polypropylene (PP), Metallized | 17.5 mOhms | -40°C ~ 105°C | Through Hole | 1.614" L x 0.669" W (41.00mm x 17.00mm) | 1.713" (43.50mm) | PC Pins | 1.476" (37.50mm) | General Purpose | - | Long Life, Low ESR |
|
EZP-E50206LTACAP FILM 20UF 10% 500VDC RADIAL |
141 | - |
|
Datasheet | Radial | 20 µF | ±10% | - | 500V | Polypropylene (PP), Metallized | 11 mOhms | -40°C ~ 85°C | Through Hole | 1.634" L x 0.787" W (41.50mm x 20.00mm) | 1.673" (42.50mm) | PC Pins | 1.476" (37.50mm) | DC Link, DC Filtering | - | Low ESR |
|
|
EZP-V80106LTTCAP FILM 10UF 10% 800V RADIAL |
225 | - |
|
Datasheet | Radial | 10 µF | ±10% | - | 800V | Polypropylene (PP), Metallized | 13.9 mOhms | -40°C ~ 105°C | Through Hole | 1.614" L x 0.669" W (41.00mm x 17.00mm) | 1.398" (35.50mm) | PC Pins | 1.476" (37.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | Long Life, Low ESR |
|
EZP-E80156MTACAP FILM 15UF 10% 800VDC RADIAL |
150 | - |
|
Datasheet | Radial - 4 Leads | 15 µF | ±10% | - | 800V | Polypropylene (PP), Metallized | 10.5 mOhms | -40°C ~ 85°C | Through Hole | 1.634" L x 0.787" W (41.50mm x 20.00mm) | 1.654" (42.00mm) | PC Pins | 1.476" (37.50mm) | DC Link, DC Filtering | - | Low ESR |
|
|
EZP-V60156LTBCAP FILM 15UF 10% 600V RADIAL |
902 | - |
|
Datasheet | Radial | 15 µF | ±10% | - | 600V | Polypropylene (PP), Metallized | 12.8 mOhms | -40°C ~ 105°C | Through Hole | 1.614" L x 0.669" W (41.00mm x 17.00mm) | 1.398" (35.50mm) | PC Pins | 1.476" (37.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | Long Life, Low ESR |
|
|
EZP-Q25226LTACAP FILM 22UF 10% 250VAC RADIAL |
383 | - |
|
Datasheet | Radial | 22 µF | ±10% | 250V | - | Polypropylene (PP), Metallized | - | -40°C ~ 85°C | Through Hole | 2.264" L x 1.181" W (57.50mm x 30.00mm) | 1.791" (45.50mm) | PC Pins | 2.067" (52.50mm) | General Purpose | - | Low ESR |
|
|
EZP-V60206MTTCAP FILM 20UF 10% 600V RADIAL |
157 | - |
|
Datasheet | Radial - 4 Leads | 20 µF | ±10% | - | 600V | Polypropylene (PP), Metallized | 10.4 mOhms | -40°C ~ 105°C | Through Hole | 1.614" L x 0.866" W (41.00mm x 22.00mm) | 1.457" (37.00mm) | PC Pins | 1.476" (37.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | Long Life, Low ESR |
|
EZP-V80146LTACAP FILM 14UF 10% 800V RADIAL |
150 | - |
|
Datasheet | Radial | 14 µF | ±10% | - | 800V | Polypropylene (PP), Metallized | 8.7 mOhms | -40°C ~ 105°C | Through Hole | 1.220" L x 1.024" W (31.00mm x 26.00mm) | 1.654" (42.00mm) | PC Pins | 1.083" (27.50mm) | DC Link, DC Filtering | - | Long Life, Low ESR |
Film Capacitors FAQ
How can I narrow the current Film Capacitors selection?
Use the available manufacturer and technical filters to compare matching parts by specifications, stock status, pricing and datasheet information.
Can EGOO help source hard-to-find or obsolete Film Capacitors parts?
Yes. Send the manufacturer part number and required quantity to our sourcing team for availability, lead-time and alternative sourcing support.
Can I request a quotation for a BOM or small-batch requirement?
Yes. EGOO supports BOM sourcing, prototype quantities and small-batch purchasing. Provide your part list and quantities for a quotation review.
What information should I provide when requesting a quote?
Please provide the target part number, manufacturer, quantity and any required date code, package or delivery requirements so our team can respond more accurately.
