Film Capacitors
Compare the current Film Capacitors Capacitors selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Capacitance | Tolerance | Voltage Rating - AC | Voltage Rating - DC | Dielectric Material | ESR (Equivalent Series Resistance) | Operating Temperature | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination | Lead Spacing | Applications | Ratings | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B32377A7306J020CAP FILM 3X30UF 5% 1.8KVDC RAD |
2,728 | - |
|
Datasheet | Radial, Can | 30 µF | ±5% | 720V | 1800V (1.8kV) | Polypropylene (PP), Metallized | - | -40°C ~ 70°C | Chassis, Stud Mount | 3.780" Dia (96.00mm) | 8.209" (208.50mm) | Terminal Block | 0.591" (15.00mm) | 3 Phase | - | - |
|
B32778J1127K000CAP FILM 120UF 10% 1.3KVDC 12DIP |
7,811 | - |
|
Datasheet | 12-DIP | 120 µF | ±10% | - | 1300V (1.3kV) | Polypropylene (PP), Metallized | 1.7 mOhms | -40°C ~ 105°C | Through Hole | 2.264" L x 5.118" W (57.50mm x 130.00mm) | 2.283" (58.00mm) | PC Pins | 2.067" (52.50mm) | DC Link, DC Filtering | - | Long Life |
|
|
B32377B4107J080CAP FILM 3X100UF 5% 1.2KVDC RAD |
6,935 | - |
|
Datasheet | Radial, Can | 100 µF | ±5% | 480V | 1200V (1.2kV) | Polypropylene (PP), Metallized | - | -40°C ~ 70°C | Chassis, Stud Mount | 3.780" Dia (96.00mm) | 10.925" (277.50mm) | Terminal Block | 0.591" (15.00mm) | 3 Phase | - | - |
|
|
B32377A5107J030CAP FILM 3X100UF 5% 1.35KVDC RAD |
8,339 | - |
|
Datasheet | Radial, Can | 100 µF | ±5% | 530V | 1350V (1.35kV) | Polypropylene (PP), Metallized | - | -40°C ~ 70°C | Chassis, Stud Mount | 4.567" Dia (116.00mm) | 9.390" (238.50mm) | Terminal Block | 0.591" (15.00mm) | 3 Phase | - | - |
|
|
B32377A7356J080CAP FILM 3X35UF 5% 1.95KVDC RAD |
8,256 | - |
|
Datasheet | Radial, Can | 35 µF | ±5% | 780V | 1950V (1.95kV) | Polypropylene (PP), Metallized | - | -40°C ~ 70°C | Chassis, Stud Mount | 4.567" Dia (116.00mm) | 7.972" (202.50mm) | Terminal Block | 0.591" (15.00mm) | 3 Phase | - | - |
|
|
B32778J8277K000CAP FILM 270UF 10% 800VDC 12-DIP |
4,545 | - |
|
Datasheet | 12-DIP | 270 µF | ±10% | - | 800V | Polypropylene (PP), Metallized | 1.2 mOhms | -40°C ~ 105°C | Through Hole | 2.264" L x 5.118" W (57.50mm x 130.00mm) | 2.283" (58.00mm) | PC Pins | 2.067" (52.50mm) | DC Link, DC Filtering | - | Long Life |
|
B25620B0148K703CAP FILM 1400UF 10% 700VDC RAD |
3,263 | - |
|
Datasheet | Radial, Can | 1400 µF | ±10% | - | 700V | Polypropylene (PP), Metallized | - | -55°C ~ 75°C | Chassis, Stud Mount | 4.567" Dia (116.00mm) | 5.512" (140.00mm) | Threaded, Female | 1.969" (50.00mm) | DC Link, DC Filtering | - | - |
|
B25645A1258K003MODULAR DCR 2525UF - 1100V - 140 |
1 | - |
|
Datasheet | Module | 2525 µF | ±10% | - | 1100V (1.1kV) | Polypropylene (PP) | - | -40°C ~ 75°C | Chassis Mount | 8.661" L x 4.528" W (220.00mm x 115.00mm) | 8.543" (217.00mm) | Connector | - | DC Link, DC Filtering | - | - |
|
B32594C6684J008CAP FILM 0.68UF 5% 400VDC RADIAL |
3,256 | - |
|
Datasheet | Radial | 0.68 µF | ±5% | 200V | 400V | Polyester, Polyethylene Terephthalate (PET) - Stacked | - | -55°C ~ 125°C | Through Hole | 1.240" L x 0.315" W (31.50mm x 8.00mm) | 0.630" (16.00mm) | PC Pins - Long Leads | 1.083" (27.50mm) | General Purpose | - | - |
|
B32686A0224KCAP FILM 0.22UF 10% 1KVDC RADIAL |
6,062 | - |
|
Datasheet | Radial | 0.22 µF | ±10% | 400V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -55°C ~ 100°C | Through Hole | 1.654" L x 0.630" W (42.00mm x 16.00mm) | 1.122" (28.50mm) | PC Pins | 1.476" (37.50mm) | DC Link, DC Filtering; High Pulse, DV/DT; Snubber | - | - |
Film Capacitors FAQ
How can I narrow the current Film Capacitors selection?
Use the available manufacturer and technical filters to compare matching parts by specifications, stock status, pricing and datasheet information.
Can EGOO help source hard-to-find or obsolete Film Capacitors parts?
Yes. Send the manufacturer part number and required quantity to our sourcing team for availability, lead-time and alternative sourcing support.
Can I request a quotation for a BOM or small-batch requirement?
Yes. EGOO supports BOM sourcing, prototype quantities and small-batch purchasing. Provide your part list and quantities for a quotation review.
What information should I provide when requesting a quote?
Please provide the target part number, manufacturer, quantity and any required date code, package or delivery requirements so our team can respond more accurately.
