Fixed Inductors
Compare the current Fixed Inductors Inductors, Coils, Chokes selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AS40-R22K-RC.22UH 10% AXIAL SHIELDED IND. |
2,397 | - |
|
Datasheet | AS40 | Axial | Bag | Active | - | - | 220 nH | ±10% | 1.1 A | 1.1A | Shielded | 67mOhm Max | 49 @ 25MHz | 250MHz | - | -55°C ~ 125°C | 25 MHz | - | Through Hole | Axial | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
|
AS40-272J-RC2700UH 5% AXIAL SHIELDED IND. |
3,960 | - |
|
Datasheet | AS40 | Axial | Bag | Active | - | - | 2.7 mH | ±10% | 40 mA | 25mA | Shielded | 47.3Ohm Max | 45 @ 250kHz | 920kHz | - | -55°C ~ 125°C | 250 kHz | - | Through Hole | Axial | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
PCS2D14-100T-RC10UH 30% POWER CHIP INDUCTOR |
3,607 | - |
|
Datasheet | - | Nonstandard | Tape & Reel (TR) | Active | - | - | 10 µH | ±30% | 760 mA | 700mA | Shielded | 294mOhm Max | - | - | - | -35°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.126" L x 0.126" W (3.20mm x 3.20mm) | 0.061" (1.55mm) |
|
PCS3D16-100T-RC10UH 30% POWER CHIP INDUCTOR |
1,156 | - |
|
Datasheet | - | Nonstandard | Tape & Reel (TR) | Active | - | - | 10 µH | ±30% | 550 mA | - | Shielded | 210mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.071" (1.80mm) |
|
HTC220LL-8R2M-RC8.2UH 30% HRZMNT TOROIDAL CHOKE |
1,959 | - |
|
Datasheet | - | Radial, Horizontal (Open) | Tray | Active | Toroidal | - | 8.2 µH | ±20% | 15.1 A | - | Unshielded | 5mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 1.100" Dia (27.94mm) | 0.550" (13.97mm) |
|
VTCB5825-300-40A30UH 15% @ 40A VERT.MNT. TOROID |
1,328 | - |
|
Datasheet | - | Radial, Vertical (Open) | Box | Active | Toroidal | - | 30 µH | ±15% | 40 A | - | Unshielded | 6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Through Hole | Radial, Vertical (Open) | 2.283" L x 0.984" W (58.00mm x 25.00mm) | 2.559" (65.00mm) |
|
PCS5D28-8R2N-RC8.2UH 30% POWER CHIP SHIELDED |
3,765 | - |
|
Datasheet | - | Nonstandard | Tape & Reel (TR) | Active | - | - | 8.2 µH | ±30% | 1.6 A | - | Shielded | 53mOhm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - | 0.224" L x 0.224" W (5.70mm x 5.70mm) | 0.118" (3.00mm) |
|
|
HTC220LL-471L-RC470UH 30% HRZMNT TOROIDAL CHOKE |
1,841 | - |
|
Datasheet | - | Radial, Horizontal (Open) | Tray | Active | Toroidal | - | 470 µH | ±15% | 3.7 A | - | Unshielded | 92mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 1.100" Dia (27.94mm) | 0.550" (13.97mm) |
|
|
VTC220LL-102L-RC1000UH30% VRTMNT TOROIDAL CHOKE |
4,910 | - |
|
Datasheet | - | Radial, Vertical (Open) | Tray | Active | Toroidal | - | 1 mH | ±15% | 2.4 A | - | Unshielded | 216mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 1.100" Dia x 0.550" L (27.94mm x 13.97mm) | - |
|
PCS124-101M-RC100UH 20% POWER CHIP SHIELDED |
2,029 | - |
|
Datasheet | - | Nonstandard | Tape & Reel (TR) | Active | - | - | 100 µH | ±20% | 1.2 A | - | Shielded | 308mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.177" (4.50mm) |
Fixed Inductors FAQ
How can I narrow the current Fixed Inductors selection?
Use the available manufacturer and technical filters to compare matching parts by specifications, stock status, pricing and datasheet information.
Can EGOO help source hard-to-find or obsolete Fixed Inductors parts?
Yes. Send the manufacturer part number and required quantity to our sourcing team for availability, lead-time and alternative sourcing support.
Can I request a quotation for a BOM or small-batch requirement?
Yes. EGOO supports BOM sourcing, prototype quantities and small-batch purchasing. Provide your part list and quantities for a quotation review.
What information should I provide when requesting a quote?
Please provide the target part number, manufacturer, quantity and any required date code, package or delivery requirements so our team can respond more accurately.
