Single Diodes
Compare the current Single Diodes Rectifiers selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Voltage - Forward (Vf) (Max) @ If | Speed | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Capacitance @ Vr, F | Grade | Qualification | Mounting Type | Supplier Device Package | Operating Temperature - Junction |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1SS427,L3MDIODE GEN PURP 80V 100MA SOD923 |
21,295 | - |
|
Datasheet | - | SOD-923 | Tape & Reel (TR) | Active | Standard | 80 V | 100mA | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 1.6 ns | 500 nA @ 80 V | 0.3pF @ 0V, 1MHz | - | - | Surface Mount | SOD-923 | -55°C ~ 150°C |
|
1SS416,L3MDIODE SCHOTTKY 30V 100MA SOD923 |
11,909 | - |
|
Datasheet | - | SOD-923 | Tape & Reel (TR) | Active | Schottky | 30 V | 100mA | 500 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | - | 50 µA @ 30 V | 15pF @ 0V, 1MHz | - | - | Surface Mount | SOD-923 | 125°C (Max) |
|
1SS413,L3MDIODE SCHOTTKY 20V 50MA FSC |
79,470 | - |
|
Datasheet | - | 2-SMD, Flat Leads | Tape & Reel (TR) | Active | Schottky | 20 V | 50mA | 550 mV @ 50 mA | Small Signal =< 200mA (Io), Any Speed | - | 500 nA @ 20 V | 3.9pF @ 0V, 1MHz | - | - | Surface Mount | fSC | 125°C (Max) |
|
CUS05S30,H3FDIODE SCHOTTKY 30V 500MA USC |
69,307 | - |
|
Datasheet | - | SC-76, SOD-323 | Tape & Reel (TR) | Active | Schottky | 30 V | 500mA | 340 mV @ 100 mA | Fast Recovery =< 500ns, > 200mA (Io) | - | 150 µA @ 10 V | 55pF @ 0V, 1MHz | - | - | Surface Mount | USC | 125°C (Max) |
|
|
CUS05S40,H3FDIODE SCHOTTKY 40V 500MA USC |
58,165 | - |
|
Datasheet | - | SC-76, SOD-323 | Tape & Reel (TR) | Active | Schottky | 40 V | 500mA | 350 mV @ 100 mA | Fast Recovery =< 500ns, > 200mA (Io) | - | 30 µA @ 10 V | 42pF @ 0V, 1MHz | - | - | Surface Mount | USC | 125°C (Max) |
|
1SS294,LFDIODE SCHOTTKY 40V 100MA S-MINI |
7,488 | - |
|
Datasheet | - | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | Schottky | 40 V | 100mA | 600 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | - | 5 µA @ 40 V | 25pF @ 0V, 1MHz | - | - | Surface Mount | S-Mini | 125°C (Max) |
|
CTS05S30,L3FDIODE SCHOTTKY 30V 500MA CST2 |
35,584 | - |
|
Datasheet | - | SOD-882 | Tape & Reel (TR) | Active | Schottky | 30 V | 500mA | 340 mV @ 100 mA | Fast Recovery =< 500ns, > 200mA (Io) | - | 150 µA @ 10 V | 55pF @ 0V, 1MHz | - | - | Surface Mount | CST2 | 125°C (Max) |
|
CUS10F30,H3FDIODE SCHOTTKY 30V 1A USC |
24,454 | - |
|
Datasheet | - | SC-76, SOD-323 | Tape & Reel (TR) | Active | Schottky | 30 V | 1A | 500 mV @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 50 µA @ 30 V | 170pF @ 0V, 1MHz | - | - | Surface Mount | USC | 125°C (Max) |
|
|
CUS10S40,H3FDIODE SCHOTTKY 40V 1A USC |
43,852 | - |
|
Datasheet | - | SC-76, SOD-323 | Tape & Reel (TR) | Active | Schottky | 40 V | 1A | 400 mV @ 500 mA | Fast Recovery =< 500ns, > 200mA (Io) | - | 150 µA @ 40 V | 120pF @ 0V, 1MHz | - | - | Surface Mount | USC | 125°C (Max) |
|
|
1SS417,L3MDIODE SCHOTTKY 40V 100MA FSC |
30,355 | - |
|
Datasheet | - | 2-SMD, Flat Leads | Tape & Reel (TR) | Active | Schottky | 40 V | 100mA | 620 mV @ 50 mA | Small Signal =< 200mA (Io), Any Speed | - | 5 µA @ 40 V | 15pF @ 0V, 1MHz | - | - | Surface Mount | fSC | 125°C (Max) |
Single Diodes FAQ
How can I narrow the current Single Diodes selection?
Use the available manufacturer and technical filters to compare matching parts by specifications, stock status, pricing and datasheet information.
Can EGOO help source hard-to-find or obsolete Single Diodes parts?
Yes. Send the manufacturer part number and required quantity to our sourcing team for availability, lead-time and alternative sourcing support.
Can I request a quotation for a BOM or small-batch requirement?
Yes. EGOO supports BOM sourcing, prototype quantities and small-batch purchasing. Provide your part list and quantities for a quotation review.
What information should I provide when requesting a quote?
Please provide the target part number, manufacturer, quantity and any required date code, package or delivery requirements so our team can respond more accurately.
