TVS Diodes
Browse available TVS Diodes components by manufacturer and part number. Review stock status, datasheets and key technical parameters to compare suitable options for design, maintenance, replacement or purchasing.
If you already have a target MPN or BOM, send it to EGOO with the required quantity. Our sourcing team can check availability, lead time and quotation options, including hard-to-find and obsolete parts.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ESD05B1ZTVS DIODE 5VWM 11VC 0201 |
3,201 | - |
|
Datasheet | 0201 (0603 Metric) | - | Bulk | Active | Zener | - | 1 | 5V (Max) | 5.8V | 11V | 17A (8/20µs) | 170W | No | General Purpose | 25pF @ 1MHz | -50°C ~ 125°C (TJ) | - | - | Surface Mount | 0201 |
|
DF2S30ASL,L3FSOD-962 VRMW 23V 1UA TVS DIODES |
3,562 | - |
|
Datasheet | 2-SMD, No Lead | - | Tape & Reel (TR) | Active | Zener | 1 | - | 23V (Max) | 28V | 58V | 2.5A (8/20µs) | 145W | No | General Purpose | 7.5pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
|
DF2S16ASL,L3FSOD-962 VRMW 12V 1UA TVS DIODES |
6,208 | - |
|
Datasheet | 2-SMD, No Lead | - | Tape & Reel (TR) | Active | Zener | 1 | - | 12V (Max) | 15.3V | 35V | 2.5A (8/20µs) | 87W | No | General Purpose | 10pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
|
DF2S20ASL,L3FSOD-962 VRMW 15V 1UA TVS DIODES |
2,354 | - |
|
Datasheet | 2-SMD, No Lead | - | Tape & Reel (TR) | Active | Zener | 1 | - | 15V (Max) | 18.8V | 42V | 2.5A (8/20µs) | 105W | No | General Purpose | 9.5pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
|
DF2S12ASL,L3FSOD-962 VRMW 9V 1UA TVS DIODES |
7,147 | - |
|
Datasheet | 2-SMD, No Lead | - | Tape & Reel (TR) | Active | Zener | 1 | - | 9V (Max) | 11.4V | 29V | 2.5A (8/20µs) | 72W | No | General Purpose | 13pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
|
DF2S24ASL,L3FSOD-962 VRMW 19V 1UA TVS DIODES |
2,674 | - |
|
Datasheet | 0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | 1 | - | 19V (Max) | 22.8V | 47V | 2.5A (8/20µs) | 117W | No | General Purpose | 8.5pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
|
DF2S10ASL,L3FSOD-962 VRMW 8V AT 1UA TVS DIODE |
5,929 | - |
|
Datasheet | 0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | 1 | - | 8V (Max) | 9.4V | 24V | 2.5A (8/20µs) | 60W | No | General Purpose | 16pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
ESDBK3V3TVS DIODE 3.3VWM 9VC SOD-882 |
3,625 | - |
|
Datasheet | SOD-882 | - | Bulk | Active | Zener | - | 1 | 3.3V | 4V | 9V | 7A (8/20µs) | 60W | No | General Purpose | 15pF @ 1MHz | -50°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-882 (DFN1006-2) |
|
|
PESD6V3S1ULYLPESD6V3S1UL/SOD882/DFN1006-2 |
6,336 | - |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 6.3V (Max) | 7.1V | 13.4V (Typ) | 10.4A (8/20µs) | - | No | General Purpose | 82pF @ 1MHz | -55°C ~ 150°C (TA) | - | - | Surface Mount | DFN1006-2 |
|
|
PESD8V0S1ULYLPESD8V0S1UL/SOD882/DFN1006-2 |
2,806 | - |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 8V (Max) | 8.65V | 15.5V (Typ) | 8.5A (8/20µs) | - | No | - | 70pF @ 1MHz | -55°C ~ 150°C (TA) | Automotive | AEC-Q101 | Surface Mount | DFN1006-2 |
|
|
PESD3V3L1BSFYLPESD3V3L1BSF/SOD962-2/SOD962-2 |
9,024 | - |
|
Datasheet | 0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 3.3V (Max) | 7.3V (Typ) | 5.6V (Typ) | 20A (8/20µs) | - | No | Telecom | 32.5pF @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | DSN0603-2 |
|
|
D12V0HE1U2LP-7BGENERAL PROTECTION PP X1-DFN1006 |
2,701 | - |
|
Datasheet | 0402 (1006 Metric) | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | X1-DFN1006-2 |
|
|
PTVS6V3Z1UCLZPTVS6V3Z1UCL/SOD882/DFN1006-2 |
8,434 | - |
|
Datasheet | 2-XDFN | - | Tape & Reel (TR) | Active | Zener | 1 | - | 6.3V (Max) | 6.4V | 12V | 40A (8/20µs) | - | No | General Purpose | 100pF @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | DFN1006-2 |
|
|
PTVS5V0Z1UCLZPTVS5V0Z1UCL/SOD882/DFN1006-2 |
8,066 | - |
|
Datasheet | 2-XDFN | - | Tape & Reel (TR) | Active | Zener | 1 | - | 5V (Max) | 5.1V | 10V | 44A (8/20µs) | - | No | General Purpose | 160pF @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | DFN1006-2 |
|
|
CPDQT5V0ESPC-HFDIODE ESD 5VWM 85W 0402/DFN1006- |
5,029 | - |
|
Datasheet | 0402 (1006 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 5V (Max) | 6.8V | 20V (Typ) | 4A (8/20µs) | 85W | No | General Purpose | 0.2pF @ 1MHz | -40°C ~ 125°C (TJ) | - | - | Surface Mount | DFN1006-2L |
|
|
ESDHD12UCXESDHD12UC/SOD323/REEL 7" Q1/T1 * |
6,949 | - |
|
Datasheet | SC-76, SOD-323 | ESDHDxxUC | Tape & Reel (TR) | Active | Zener | 1 | - | 12V (Max) | 13.3V | 35V | 15A (8/20µs) | 300W | No | General Purpose | 150pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
|
|
ESDHD03UCXESDHD03UC/SOD323/REEL 7" Q1/T1 * |
9,660 | - |
|
Datasheet | SC-76, SOD-323 | ESDHDxxUC | Tape & Reel (TR) | Active | Zener | 1 | - | 3.3V (Max) | 4V | 18V | 30A (8/20µs) | 300W | No | General Purpose | 300pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
|
|
ESDHD15UCXESDHD15UC/SOD323/REEL 7" Q1/T1 * |
9,450 | - |
|
Datasheet | SC-76, SOD-323 | ESDHDxxUC | Tape & Reel (TR) | Active | Zener | 1 | - | 15V (Max) | 16.3V | 45V | 10A (8/20µs) | 300W | No | General Purpose | 120pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
|
|
ESDHD24UCXESDHD24UC/SOD323/REEL 7" Q1/T1 * |
8,274 | - |
|
Datasheet | SC-76, SOD-323 | ESDHDxxUC | Tape & Reel (TR) | Active | Zener | 1 | - | 24V (Max) | 26V | 55V | 6A (8/20µs) | 300W | No | General Purpose | 80pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
|
|
ESDHD05UCXESDHD05UC/SOD323/REEL 7" Q1/T1 * |
3,018 | - |
|
Datasheet | SC-76, SOD-323 | ESDHDxxUC | Tape & Reel (TR) | Active | Zener | 1 | - | 5V (Max) | 6V | 20V | 30A (8/20µs) | 300W | No | General Purpose | 300pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
TVS Diodes FAQ
What TVS Diodes components can I source from EGOO?
You can browse available TVS Diodes product families, manufacturers and part numbers on this page, then review stock, datasheets and technical information for suitable options.
Can EGOO help with hard-to-source or obsolete TVS Diodes parts?
Yes. EGOO provides sourcing support for shortage, obsolete and hard-to-find electronic components. Send us the target manufacturer part number and quantity for checking.
Does EGOO support BOM and small-batch sourcing?
Yes. We support BOM sourcing, prototype requirements and small-batch supply, together with stock, lead-time and quotation assistance.
How do I request pricing and availability?
Submit the manufacturer part number, required quantity and any package, date-code or delivery requirements through the RFQ form, and our team will review available sourcing options.
