Common Mode Chokes
Compare the current Common Mode Chokes Filters selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Voltage Rating - DC | Voltage Rating - AC | Operating Temperature | Ratings | Approval Agency | Features | Mounting Type | Size / Dimension | Height (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TLF14CBH6830R2K1CMC 68MH 200MA 2LN TH |
4,522 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 68 mH @ 1 kHz | 200mA | 6.5Ohm | - | 250V | -25°C ~ 105°C | - | - | - | - | - |
-MC-Series.jpg "MCF08062G470-T")
|
MCF08062G470-TCMC 100MA 2LN 47 OHM SMD |
4,211 | - |
|
Datasheet | 0302 (0806 Metric), 4 Lead | Signal Line | 2 | 47 Ohms @ 100 MHz | - | 100mA | 4Ohm | 5V | - | -40°C ~ 85°C | - | - | - | - | - |
|
|
MCF08062G900-TCMC 100MA 2LN 90 OHM SMD |
1,873 | - |
|
Datasheet | 0302 (0806 Metric), 4 Lead | Signal Line | 2 | 90 Ohms @ 100 MHz | - | 100mA | 5Ohm | 5V | - | -40°C ~ 85°C | - | - | - | - | - |
.jpg "MCF12102G900-T")
|
MCF12102G900-TCMC 100MA 2LN 90 OHM SMD |
3,732 | - |
|
Datasheet | 0504 (1210 Metric), 4 Lead | Signal Line | 2 | 90 Ohms @ 100 MHz | - | 100mA | 4.5Ohm | 5V | - | -40°C ~ 85°C | - | - | - | - | - |
|
MCF20104G900-TCMC 100MA 4LN 90 OHM SMD |
4,043 | - |
|
Datasheet | 0804 (2010 Metric), 8 Lead | Signal Line | 4 | 90 Ohms @ 100 MHz | - | 100mA | 4.5Ohm | 5V | - | -40°C ~ 85°C | - | - | - | - | - |
|
BU05MC08TCMC 500MA 3LN 700 OHM SMD |
2,853 | - |
|
Datasheet | 6-SMD, Gull Wing | Signal Line | 3 | 700 Ohms @ 60 MHz | - | 500mA | 110mOhm | 50V | - | -25°C ~ 105°C | - | - | - | - | - |
|
BU08RA11CMC 4A 2LN 1K OHM TH |
2,534 | - |
|
Datasheet | Vertical, No Base, 4 PC Pin | Power, Signal Line | 2 | 1 kOhms @ 250 MHz | - | 4A | 13mOhm | 50V | - | -25°C ~ 105°C | - | - | - | - | - |
|
|
BU08RA16CMC 3A 2LN 1.2K OHM TH |
3,109 | - |
|
Datasheet | Vertical, No Base, 4 PC Pin | Signal Line | 2 | 1.2 kOhms @ 200 MHz | - | 3A | 11mOhm | 50V | - | -25°C ~ 105°C | - | - | - | - | - |
|
|
TLF24HB1031R0K1CMC 1A 2LN TH |
2,945 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | - | 1A | 345mOhm | - | 250V | -25°C ~ 105°C | - | - | - | - | - |
|
|
TLF24HB1223R0K1CMC 3A 2LN TH |
4,399 | - |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | - | 3A | 45mOhm | - | 250V | -25°C ~ 105°C | - | - | - | - | - |
Common Mode Chokes FAQ
How can I narrow the current Common Mode Chokes selection?
Use the available manufacturer and technical filters to compare matching parts by specifications, stock status, pricing and datasheet information.
Can EGOO help source hard-to-find or obsolete Common Mode Chokes parts?
Yes. Send the manufacturer part number and required quantity to our sourcing team for availability, lead-time and alternative sourcing support.
Can I request a quotation for a BOM or small-batch requirement?
Yes. EGOO supports BOM sourcing, prototype quantities and small-batch purchasing. Provide your part list and quantities for a quotation review.
What information should I provide when requesting a quote?
Please provide the target part number, manufacturer, quantity and any required date code, package or delivery requirements so our team can respond more accurately.
