FET, MOSFET Arrays
Compare the current FET, MOSFET Arrays FETs, MOSFETs selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Configuration | FET Feature | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Input Capacitance (Ciss) (Max) @ Vds | Power - Max | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MSCSM170AM039CD3AGMOSFET 2N-CH 1700V 523A |
2 | - |
|
Datasheet | - | Module | Bulk | Active | Silicon Carbide (SiC) | 2 N Channel (Phase Leg) | - | 1700V (1.7kV) | 523A (Tc) | 5mOhm @ 270A, 20V | 3.3V @ 22.5mA | 1602nC @ 20V | 29700pF @ 1000V | 2.4kW (Tc) | -40°C ~ 175°C (TJ) | - | - | Chassis Mount | - |
|
APTM50H14FT3GMOSFET 4N-CH 500V 26A SP3 |
13 | - |
|
Datasheet | - | SP3 | Bulk | Active | MOSFET (Metal Oxide) | 4 N-Channel (Full Bridge) | - | 500V | 26A | 168mOhm @ 13A, 10V | 5V @ 1mA | 72nC @ 10V | 3259pF @ 25V | 208W | -40°C ~ 150°C (TJ) | - | - | Chassis Mount | SP3 |
|
APTC60DSKM24T3GMOSFET 2N-CH 600V 95A SP3 |
7 | - |
|
Datasheet | CoolMOS™ | SP3 | Tray | Active | MOSFET (Metal Oxide) | 2 N Channel (Dual Buck Chopper) | - | 600V | 95A | 24mOhm @ 47.5A, 10V | 3.9V @ 5mA | 300nC @ 10V | 14400pF @ 25V | 462W | -40°C ~ 150°C (TJ) | - | - | Chassis Mount | SP3 |
|
APTM50HM65FT3GMOSFET 4N-CH 500V 51A SP3 |
8 | - |
|
Datasheet | - | SP3 | Bulk | Active | MOSFET (Metal Oxide) | 4 N-Channel (Full Bridge) | - | 500V | 51A | 78mOhm @ 25.5A, 10V | 5V @ 2.5mA | 140nC @ 10V | 7000pF @ 25V | 390W | -40°C ~ 150°C (TJ) | - | - | Chassis Mount | SP3 |
|
APTM50AM38STGMOSFET 2N-CH 500V 90A SP4 |
6 | - |
|
Datasheet | - | SP4 | Bulk | Active | MOSFET (Metal Oxide) | 2 N-Channel (Half Bridge) | - | 500V | 90A | 45mOhm @ 45A, 10V | 5V @ 5mA | 246nC @ 10V | 11200pF @ 25V | 694W | -40°C ~ 150°C (TJ) | - | - | Chassis Mount | SP4 |
|
|
MSCSM70TLM19C3AGMOSFET 4N-CH 700V 124A SP3F |
5 | - |
|
Datasheet | - | Module | Bulk | Active | Silicon Carbide (SiC) | 4 N-Channel (Three Level Inverter) | - | 700V | 124A (Tc) | 19mOhm @ 40A, 20V | 2.4V @ 4mA | 215nC @ 20V | 4500pF @ 700V | 365W (Tc) | -40°C ~ 175°C (TJ) | - | - | Chassis Mount | SP3F |
|
|
MSCSM70VR1M10CT3AGMOSFET 2N-CH 700V 241A |
4 | - |
|
Datasheet | - | Module | Bulk | Active | Silicon Carbide (SiC) | 2 N Channel (Phase Leg) | - | 700V | 241A (Tc) | 9.5mOhm @ 80A, 20V | 2.4V @ 8mA | 430nC @ 20V | 9000pF @ 700V | 690W (Tc) | -40°C ~ 175°C (TJ) | - | - | Chassis Mount | - |
|
MSCM20XM10T3XGMOSFET 6N-CH 200V 108A SP3X |
9 | - |
|
Datasheet | - | Module | Bulk | Active | MOSFET (Metal Oxide) | 6 N-Channel (3-Phase Bridge) | - | 200V | 108A (Tc) | 9.7mOhm @ 81A, 10V | 5V @ 250µA | 161nC @ 10V | 10700pF @ 50V | 341W (Tc) | -40°C ~ 125°C (Tc) | - | - | Chassis Mount | SP3X |
.jpg "MSCSM120HM31CT3AG")
|
MSCSM120HM31CT3AGMOSFET 4N-CH 1200V 89A SP3F |
3 | - |
|
Datasheet | - | Module | Tube | Active | Silicon Carbide (SiC) | 4 N-Channel | - | 1200V (1.2kV) | 89A (Tc) | 31mOhm @ 40A, 20V | 2.8V @ 1mA | 232nC @ 20V | 3020pF @ 1000V | 395W (Tc) | -40°C ~ 175°C (TJ) | - | - | Chassis Mount | SP3F |
|
MSCSM70AM07CT3AGMOSFET 2N-CH 700V 353A SP3F |
3 | - |
|
Datasheet | - | Module | Tube | Active | Silicon Carbide (SiC) | 2 N Channel (Phase Leg) | - | 700V | 353A (Tc) | 6.4mOhm @ 120A, 20V | 2.4V @ 12mA | 645nC @ 20V | 13500pF @ 700V | 988W (Tc) | -40°C ~ 175°C (TJ) | - | - | Chassis Mount | SP3F |
FET, MOSFET Arrays FAQ
How can I narrow the current FET, MOSFET Arrays selection?
Use the available manufacturer and technical filters to compare matching parts by specifications, stock status, pricing and datasheet information.
Can EGOO help source hard-to-find or obsolete FET, MOSFET Arrays parts?
Yes. Send the manufacturer part number and required quantity to our sourcing team for availability, lead-time and alternative sourcing support.
Can I request a quotation for a BOM or small-batch requirement?
Yes. EGOO supports BOM sourcing, prototype quantities and small-batch purchasing. Provide your part list and quantities for a quotation review.
What information should I provide when requesting a quote?
Please provide the target part number, manufacturer, quantity and any required date code, package or delivery requirements so our team can respond more accurately.
