Diode Arrays
Compare the current Diode Arrays Rectifiers selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Diode Configuration | Technology | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) (per Diode) | Voltage - Forward (Vf) (Max) @ If | Speed | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Operating Temperature - Junction | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MF400K04F3-BPDIODE MODULE GP 400V 200A F3 |
6 | - |
|
Datasheet | - | F3 Module | Bulk | Active | 1 Pair Common Anode | Standard | 400 V | 200A | 1.35 V @ 200 A | Fast Recovery =< 500ns, > 200mA (Io) | 135 ns | 1 mA @ 400 V | -40°C ~ 150°C | - | - | Chassis Mount | F3 |
|
MF200DU06FJ-BPDIODE MOD GP 600V 100A FJ/SOT227 |
15 | - |
|
Datasheet | - | SOT-227-4 | Bulk | Active | 2 Independent | Standard | 600 V | 100A | 1.4 V @ 100 A | Fast Recovery =< 500ns, > 200mA (Io) | 105 ns | 500 µA @ 600 V | -40°C ~ 150°C | - | - | Chassis Mount | FJ/SOT-227 |
|
MD60K16D1-BPDIODE MODULE GP 1600V 60A D1 |
41 | - |
|
Datasheet | - | D1 | Bulk | Active | 1 Pair Common Cathode | Standard | 1600 V | 60A | 1.45 V @ 200 A | Standard Recovery >500ns, > 200mA (Io) | - | 5 mA @ 1600 V | -40°C ~ 150°C | - | - | Chassis Mount | D1 |
|
MF200C12F2-BPDIODE MODULE GEN PURP 200A F2 |
8 | - |
|
Datasheet | - | F2 Module | Bulk | Active | 1 Pair Series Connection | Standard | - | 200A | 2.8 V @ 200 A | Fast Recovery =< 500ns, > 200mA (Io) | 110 ns | 1 mA @ 1200 V | -40°C ~ 150°C | - | - | Chassis Mount | F2 |
|
MD165C16D2-BPDIODE MODULE GP 1600V 165A D2 |
3 | - |
|
Datasheet | - | D2 | Bulk | Active | 1 Pair Series Connection | Standard | 1600 V | 165A | 1.4 V @ 300 A | Standard Recovery >500ns, > 200mA (Io) | - | 9 mA @ 1600 V | -40°C ~ 150°C | - | - | Chassis Mount | D2 |
|
BAT64-04-TPDIODE ARR SCHOTT 40V 250MA SOT23 |
799 | - |
|
Datasheet | - | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | 1 Pair Series Connection | Schottky | 40 V | 250mA | 750 mV @ 100 mA | Fast Recovery =< 500ns, > 200mA (Io) | - | 2 µA @ 25 V | -55°C ~ 150°C | - | - | Surface Mount | SOT-23 |
|
MBRB1040CT-TPDIODE ARRAY SCHOTT 40V 10A D2PAK |
800 | - |
|
Datasheet | - | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Not For New Designs | 1 Pair Common Cathode | Schottky | 40 V | 10A | 550 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 500 µA @ 40 V | -55°C ~ 125°C | - | - | Surface Mount | D2PAK |
|
|
MBRB10200CTS-TPDIODE ARRAY SCHOT 200V 10A D2PAK |
1,535 | - |
|
Datasheet | - | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Not For New Designs | 1 Pair Common Cathode | Schottky | 200 V | 10A | 930 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 10 µA @ 200 V | -55°C ~ 175°C | - | - | Surface Mount | D2PAK |
|
|
MF200K04F3-BPDIODE MODULE GP 400V 100A F3 |
10 | - |
|
Datasheet | - | F3 Module | Bulk | Active | 1 Pair Common Anode | Standard | 400 V | 100A | 1.35 V @ 100 A | Fast Recovery =< 500ns, > 200mA (Io) | 95 ns | 500 µA @ 400 V | -40°C ~ 150°C | - | - | Chassis Mount | F3 |
|
|
MD36C16D1-BPDIODE MODULE GP 1600V 36A D1 |
100 | - |
|
Datasheet | - | D1 | Bulk | Active | 1 Pair Series Connection | Standard | 1600 V | 36A | 1.4 V @ 100 A | Standard Recovery >500ns, > 200mA (Io) | - | 5 mA @ 1600 V | -40°C ~ 150°C | - | - | Chassis Mount | D1 |
Diode Arrays FAQ
How can I narrow the current Diode Arrays selection?
Use the available manufacturer and technical filters to compare matching parts by specifications, stock status, pricing and datasheet information.
Can EGOO help source hard-to-find or obsolete Diode Arrays parts?
Yes. Send the manufacturer part number and required quantity to our sourcing team for availability, lead-time and alternative sourcing support.
Can I request a quotation for a BOM or small-batch requirement?
Yes. EGOO supports BOM sourcing, prototype quantities and small-batch purchasing. Provide your part list and quantities for a quotation review.
What information should I provide when requesting a quote?
Please provide the target part number, manufacturer, quantity and any required date code, package or delivery requirements so our team can respond more accurately.
