RF Antennas
Compare the current RF Antennas RF and Wireless selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | RF Family/Standard | Frequency Group | Frequency (Center/Band) | Frequency Range | Antenna Type | Number of Bands | VSWR | Return Loss | Gain | Power - Max | Features | Termination | Ingress Protection | Grade | Qualification | Mounting Type | Height (Max) | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MA111.C.LB.001RF ANT 850MHZ/900MHZ DOME PNL MT |
2,242 | - |
|
Datasheet | Ultima | Bag | Active | Cellular, Navigation | Wide Band | 850MHz, 900MHz, 1.575GHz, 1.602GHz, 1.8GHz, 1.9GHz, 2.1GHz | 824MHz ~ 960MHz, 1.574GHz ~ 1.606GHz, 1.71GHz ~ 2.17GHz | Dome | 7 | 2.5, 2, 2, 3.5, 3, 3 | - | 1.5dBi, 3dBi, -1.4dB, -1.3dBi, 2dBi, 4dBi, 2.5dBi | - | Cable - 3m, LNA, Filter | SMA Male (2) | IP67 | - | - | Panel Mount | 0.772" (19.60mm) | CDMA, GLONASS, GPS, GSM, UMTS |
|
LMA101.A.BI.001RF ANT 829MHZ/2.2GHZ MOD SMA MAL |
134 | - |
|
Datasheet | GEMINI | Box | Active | Cellular | Wide Band | 829MHz, 2.2GHz | 698MHz ~ 960MHz, 1.71GHz ~ 2.69GHz | Module | 2 | - | - | 5.1dBi | - | - | SMA Male | IP67 | - | - | Magnetic, Chassis Mount | 1.437" (36.50mm) | LTE |
|
IS.01.B.305111RF ANT 430MHZ DOME SMA MALE PAN |
3,511 | - |
|
Datasheet | - | Bag | Active | - | UHF (300MHz ~ 1GHz) | 430MHz | 400MHz ~ 460MHz | Dome | 1 | 1.8 | - | 1.6dBi | 5 W | - | SMA Male | IP69K | - | - | Panel Mount | 1.142" (29.00mm) | - |
|
TLS.90.205111SHOCKWAVE 868/915MHZ TERMINAL RO |
1,672 | - |
|
Datasheet | - | Box | Active | General ISM | UHF (300MHz ~ 1GHz) | 868MHz, 915MHz | 850MHz ~ 880MHz, 902MHz ~ 928MHz | Dome | 2 | - | -20dB | 1.67dBi, 1.58dBi, 1.57dBi, 1.61dBi, 1.9dBi, 2.46dBi | 100 W | Cable - 2m | SMA Male | IP67, IP69K | - | - | Panel Mount | 3.128" (79.45mm) | ISM |
|
TS.16.0111GPS/GLONASS/GALILEO/BEIDOU ACTIV |
3,123 | - |
|
Datasheet | - | Bag | Active | Navigation | Wide Band | 1.561GHz, 1.575GHz, 1.603GHz | - | Module | 3 | 2 | - | 1.19dBi, 2.29dBi, 1.4dBi | - | LNA, Filter | SMA Male | IP67 | - | - | Surface Mount | 2.362" (60.00mm) | BeiDou, Galileo, GLONASS, GNSS, GPS, IRNSS, QZSS, SBAS |
|
IS.04.B.301111RF ANT 869MHZ DOME SMA MALE PAN |
4,914 | - |
|
Datasheet | - | Bag | Active | - | UHF (300MHz ~ 1GHz) | 869MHz | 868MHz ~ 870MHz | Dome | 1 | 2.5 | -21.93dB | 2.09dBi | 10 W | - | SMA Male | IP69K | - | - | Panel Mount | 1.142" (29.00mm) | - |
|
IS.05.B.301111RF ANT 915MHZ DOME SMA ML PNL MT |
3,846 | - |
|
Datasheet | Hercules | Bag | Active | - | UHF (300MHz ~ 1GHz) | 915MHz | 902MHz ~ 928MHz | Dome | 1 | 2.5 | -17.54dB | 3.14dBi | 10 W | Cable - 3m | SMA Male | IP67, IP69K | - | - | Panel Mount | 1.122" (28.50mm) | - |
|
MA114.B.LB.0012IN1 GNSS 5G/4G ANTENNA |
2,202 | - |
|
Datasheet | - | Bulk | Active | Cellular, Navigation, WiFi | Wide Band | 657.5MHz, 752MHz, 892MHz, 1.4725GHz, 1.561GHz, 1.575GHz, 1.602GHz, 1.955GHz, 2.495GHz, 3.75GHz, 4.7GHz, 5.5375GHz | 617MHz ~ 698MHz, 698MHz ~ 806MHz, 824MHz ~ 960MHz, 1.427GHz ~ 1.518GHz, 1.71GHz ~ 2.2GHz, 2.3GHz ~ 2.69GHz, 3.3GHz ~ 4.2GHz, 4.4GHz ~ 5GHz, 5.15GHz ~ 5.925GHz | Module | 12 | 2, 3 | - | 2.8dBi, 4dBi, 4.1dBi, 3.8dBi, 28dBi, 28dBi, 28dBi, 5.2dBi, 6.1dBi, 5.7dBi, 5.4dBi, 7.3dBi | 10 W | Cable - 1m, LNA, Filter | SMA Male (2) | IP67 | - | - | Panel Mount | 1.378" (35.00mm) | 3G, 4G, 5G, Beidou, GLONASS, GPS, GNSS, LTE, Wi-Fi |
|
MA284.LBIC.001GENESIS II - 4IN1 GNSS:2M RG174 |
2,321 | - |
|
Datasheet | - | Bag | Active | Cellular, Navigation, WiFi | Wide Band | 750.5MHz, 869MHz, 920MHz, 1.561GHz, 1.575GHz, 1.602GHz, 1.795GHz, 1.92GHz, 2.045GHz, 2.4GHz, 2.495GHz | 698MHz ~ 803MHz, 824MHz ~ 894MHz, 880MHz ~ 960MHz, 1.559GHz ~ 1.563GHz, 1.574GHz ~ 1.576GHz, 1.597GHz ~ 1.607GHz, 1.71GHz ~ 1.88GHz, 1.85GHz ~ 1.99GHz, 1.92GHz ~ 2.17GHz, 2.3GHz ~ 2.69GHz, 2.4GHz ~ 2. | Module | 12 | - | -6dB, -10dB | 1.99dBi, 2.34dBi, 1.98dBi, 2.3dBi, 3.15dBi, 3.63dBi, 4.11dBi, 2.85dBi, -3.01dBi, -2.07dBi | - | Cable - 1m, LNA, Filter | RP-SMA Male (1), SMA Male (2) | IP67 | - | - | Adhesive | 0.512" (13.00mm) | Beidou, DCS, Galileo, GLONASS, GNSS, GPS, GSM, LTE, PCS, Wi-Fi |
|
MA950.A.LBICG.005RF ANT 829MHZ/1.575GHZ MOD ADH |
2,357 | - |
|
Datasheet | Guardian | Box | Active | Cellular, Navigation, WiFi | Wide Band | 829MHz, 1.575GHz, 1.94GHz, 2.4GHz, 2.59GHz, 3.45GHz, 5.8GHz | 698MHz ~ 960MHz, 1.575GHz, 1.71GHz ~ 2.17GHz, 2.4GHz ~ 2.69GHz, 3.3GHz ~ 3.6GHz, 5.8GHz | Module | 7 | 2 | -10dB | 28dB | - | Cable - 1m, LNA, Filter | SMA Male | IP67 | - | - | Adhesive | 0.787" (20.00mm) | Beidou, GLONASS, GPS, GNSS, GSM, LTE, UMTS, Wi-Fi |
