Current Sense Transformers
Browse available Current Sense Transformers components by manufacturer and part number. Review stock status, datasheets and key technical parameters to compare suitable options for design, maintenance, replacement or purchasing.
If you already have a target MPN or BOM, send it to EGOO with the required quantity. Our sourcing team can check availability, lead time and quotation options, including hard-to-find and obsolete parts.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Frequency Range | Type | Current Rating (Amps) | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Current Ratio | DC Resistance (DCR) | Ratings | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
855-305/200-509CURR SENSE XFMR 200A CHAS MNT |
1,402 | - |
|
Datasheet | - | Box | Active | 50Hz ~ 60Hz | Non-Invasive (Solid Core) | 200 A | - | - | - | - | - | - | Chassis Mount | 2.362" L x 1.378" W (60.00mm x 35.00mm) | 3.173" (80.60mm) | Terminal Block |
|
|
855-305/150-209CURR SENSE XFMR 150A CHAS MNT |
4,216 | - |
|
Datasheet | - | Box | Active | 50Hz ~ 60Hz | Non-Invasive (Solid Core) | 150 A | - | - | - | - | - | - | Chassis Mount | 2.362" L x 1.378" W (60.00mm x 35.00mm) | 3.173" (80.60mm) | Terminal Block |
|
|
855-305/100-209CURR SENSE XFMR 100A CHAS MNT |
3,874 | - |
|
Datasheet | - | Box | Active | 50Hz ~ 60Hz | Non-Invasive (Solid Core) | 100 A | - | - | - | - | - | - | Chassis Mount | 2.362" L x 1.378" W (60.00mm x 35.00mm) | 3.173" (80.60mm) | Terminal Block |
|
2438480000CMA-812-15-5A-7.5VA-0.5 |
1,724 | - |
|
Datasheet | - | Box | Active | 50Hz | Non-Invasive (Split Core) | 1.5 kA | - | - | - | - | - | - | Chassis Mount | 6.102" L x 2.283" W (154.99mm x 57.99mm) | 7.795" (197.99mm) | Terminal Block |
|
|
855-305/750-509CURR SENSE XFMR 750A CHAS MNT |
3,999 | - |
|
Datasheet | - | Box | Active | 50Hz ~ 60Hz | Non-Invasive (Solid Core) | 750 A | - | - | - | - | - | - | Chassis Mount | 2.362" L x 1.378" W (60.00mm x 35.00mm) | 3.173" (80.60mm) | Terminal Block |
|
|
855-305/600-509CURR SENSE XFMR 600A CHAS MNT |
1,820 | - |
|
Datasheet | - | Box | Active | 50Hz ~ 60Hz | Non-Invasive (Solid Core) | 600 A | - | - | - | - | - | - | Chassis Mount | 2.362" L x 1.378" W (60.00mm x 35.00mm) | 3.173" (80.60mm) | Terminal Block |
|
855-405/600-509CURR SENSE XFMR 600A CHAS MNT |
4,107 | - |
|
Datasheet | - | Box | Active | 50Hz ~ 60Hz | Non-Invasive (Solid Core) | 600 A | - | - | - | - | - | - | Chassis Mount | 2.756" L x 1.378" W (70.00mm x 35.00mm) | 3.589" (91.15mm) | Terminal Block |
|
|
855-405/750-509CURR SENSE XFMR 750A CHAS MNT |
2,072 | - |
|
Datasheet | - | Box | Active | 50Hz ~ 60Hz | Non-Invasive (Solid Core) | 750 A | - | - | - | - | - | - | Chassis Mount | 2.756" L x 1.378" W (70.00mm x 35.00mm) | 3.589" (91.15mm) | Terminal Block |
|
|
2656290000KCMA-RCM-812D |
1,042 | - |
|
Datasheet | - | Box | Active | 50Hz | Non-Invasive (Split Core) | 18 A | - | - | - | - | - | - | DIN Rail | 6.102" L x 2.283" W (154.99mm x 57.99mm) | 7.795" (197.99mm) | Terminal Block |
|
|
RA 2000-S/SP2TRANSDUCER |
1,994 | - |
|
Datasheet | RA | Bulk | Active | 20Hz ~ 3kHz | Non-Invasive (Solid Core) | 4 A | - | - | Rogowski Coil | - | - | - | Chassis Mount | 5.512" L x 8.465" W (140.00mm x 215.00mm) | 8.780" (223.00mm) | Terminal Block |
|
|
RA 2000-S/SP4TRANSDUCER |
1,842 | - |
|
Datasheet | RA | Bulk | Active | 20Hz ~ 3kHz | Non-Invasive (Solid Core) | 4 A | - | - | Rogowski Coil | - | - | - | Chassis Mount | 5.512" L x 8.465" W (140.00mm x 215.00mm) | 8.780" (223.00mm) | Terminal Block |
|
|
RA 2000-S/SP3TRANSDUCER |
2,232 | - |
|
Datasheet | RA | Bulk | Active | 20Hz ~ 3kHz | Non-Invasive (Solid Core) | 4 A | - | - | Rogowski Coil | - | - | - | Chassis Mount | 5.512" L x 8.465" W (140.00mm x 215.00mm) | 8.780" (223.00mm) | Terminal Block |
|
|
RA 2000-T/SP2TRANSDUCER |
4,634 | - |
|
Datasheet | RA | Bulk | Active | 20Hz ~ 3kHz | Non-Invasive (Solid Core) | 4 A | - | - | Rogowski Coil | - | - | - | Chassis Mount | 5.512" L x 8.465" W (140.00mm x 215.00mm) | 8.780" (223.00mm) | Terminal Block |
|
7201CURR SENSE XFMR 10A UNI TH |
3,472 | - |
|
Datasheet | 7200 | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | 0.748" L x 0.433" W (19.00mm x 11.00mm) | 0.791" (20.10mm) | - |
|
7202CURR SENSE XFMR 20A UNI TH |
2,460 | - |
|
Datasheet | 7200 | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | 0.748" L x 0.433" W (19.00mm x 11.00mm) | 0.791" (20.10mm) | - |
|
7203CURR SENSE XFMR 35A UNI TH |
4,884 | - |
|
Datasheet | 7200 | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | 0.748" L x 0.433" W (19.00mm x 11.00mm) | 0.791" (20.10mm) | - |
|
CTX16-18294-RCURR SENSE XFMR T/H |
4,042 | - |
|
Datasheet | - | Bulk | Active | - | - | - | 8.25 mH | - | - | - | - | - | Through Hole | - | - | PC Pin |
|
55050CCURR SENSE XFMR 1:1:50 15A SMD |
4,557 | - |
|
Datasheet | 5500 | Tube | Obsolete | 50kHz ~ 500kHz | Invasive | - | 3.8 mH | - | 1:1:50 | - | 2.3mOhm Primary, 350mOhm Secondary | - | Surface Mount | 0.496" L x 0.575" W (12.60mm x 14.60mm) | 0.280" (7.10mm) | - |
|
55100CCURR SENSE XFMR 1:1:100 15A SMD |
1,660 | - |
|
Datasheet | 5500 | Tube | Obsolete | 50kHz ~ 500kHz | Invasive | - | 14.8 mH | - | 1:1:100 | - | 2.3mOhm Primary, 850mOhm Secondary | - | Surface Mount | 0.496" L x 0.575" W (12.60mm x 14.60mm) | 0.280" (7.10mm) | - |
|
55200CCURR SENSE XFMR 1:1:200 15A SMD |
1,628 | - |
|
Datasheet | 5500 | Tube | Obsolete | 50kHz ~ 500kHz | Invasive | - | 60 mH | - | 1:1:200 | - | 2.3mOhm Primary, 3.6Ohm Secondary | - | Surface Mount | 0.496" L x 0.575" W (12.60mm x 14.60mm) | 0.280" (7.10mm) | - |
