Pulse Transformers
Compare the current Pulse Transformers Transformers selection by manufacturer, stock status, datasheet and technical parameters. Use these details to narrow the list to parts that match your design, maintenance or purchasing requirements.
For a specific MPN, package, electrical rating or quantity requirement, send the details to EGOO. We can help confirm availability, quotation and alternative sourcing options.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SM91501AL-EBMS XFORMER 2-CH 1600V AECQ +125 |
4,941 | - |
|
Datasheet | SM | Tape & Reel (TR) | Active | - | 150µH | - | 1CT:1CT | Surface Mount | 0.583" L x 0.460" W (14.81mm x 11.68mm) | 0.197" (5.00mm) | -40°C ~ 125°C | Automotive | AEC-Q200 |
|
SM91074AL-E10/100 BASE T XFORMER AECQ +125 |
2,880 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | Automotive | AEC-Q200 |
|
HCTSM80102AAL-EXFMR 3.3-5V/3.3-15V,350MA PK TR |
1,745 | - |
|
Datasheet | HCT | Tape & Reel (TR) | Active | Isolation and Data Interface (Encapsulated) | 250µH | 11.0VµS | 1:2 | Surface Mount | 0.484" L x 0.425" W (12.30mm x 10.80mm) | 0.256" (6.50mm) | -40°C ~ 125°C | - | - |
|
|
SM91534AL-ETRANSF BMS CMC 6.4KVDC 6 PIN |
450 | - |
|
Datasheet | SM | Tape & Reel (TR) | Active | Battery Management | 150µH | - | 1:1 | Surface Mount | 1.102" L x 0.492" W (28.00mm x 12.50mm) | 0.374" (9.50mm) | -40°C ~ 125°C | Automotive | AEC-Q200 |
|
SM91527L-EBMS TRANSFOMER/CMC, 6PIN,SIN, DC |
157 | - |
|
Datasheet | SM | Tape & Reel (TR) | Active | - | 150µH | - | 1:1 | Surface Mount | 1.240" L x 0.492" W (31.50mm x 12.50mm) | 0.374" (9.50mm) | -40°C ~ 125°C | - | - |
|
SM353230-181N7YCHIP LAN XFMR,1 /2.5/5G,3.5X3.2X |
312 | - |
|
Datasheet | SM | Tape & Reel (TR) | Active | LAN 1/2.5/5G Base-T | 180µH | - | 1:1 | Surface Mount | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.114" (2.90mm) | -40°C ~ 85°C | - | - |
|
SM91047ELPULSE XFMR 11.875:1 5MH |
378 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | - | 5mH | - | 11.875:1 | Surface Mount | 0.531" L x 0.701" W (13.50mm x 17.80mm) | 0.500" (12.70mm) | -40°C ~ 125°C | - | - |
|
SM91509AL-EXFRMR PULSE 1:1 600UH SMD |
4,313 | - |
|
Datasheet | SM | Tape & Reel (TR) | Active | - | 600µH | - | 1:1 | Surface Mount | 0.583" L x 0.460" W (14.81mm x 11.68mm) | 0.197" (5.00mm) | -40°C ~ 125°C | Automotive | AEC-Q200 |
|
SM453230-231N7YPLAN XFMR,1/2.5/5GBE,POE+,IEEE |
4,602 | - |
|
Datasheet | SM | Tape & Reel (TR) | Active | LAN 1/2.5/5G Base-T | 230µH | - | 1:1 | Surface Mount | 0.185" L x 0.130" W (4.70mm x 3.30mm) | 0.114" (2.90mm) | -40°C ~ 85°C | - | - |
|
|
SM453230-181N7YCHIP LAN XFMR,1 /2.5/5G,4.7X3.2X |
2,054 | - |
|
Datasheet | SM | Tape & Reel (TR) | Active | LAN 1/2.5/5G Base-T | 180µH | - | 1:1 | Surface Mount | 0.185" L x 0.127" W (4.70mm x 3.22mm) | 0.114" (2.90mm) | -40°C ~ 85°C | - | - |
